Specifications
MOQ :
1 Piece
Price :
US$3000-3500
Place of Origin :
Xinxiang
Brand Name :
BETTER
Packaging Details :
Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.
Delivery Time :
Within 15 working days
Payment Terms :
L/C,T/T
Supply Ability :
50 Sets/Month
Model Number :
BXC
Product Name :
Battery-Power Transfer Cart
Frame Material :
Aluminum Alloy
Rail Gauge :
1435mm (Customized)
Power Source :
Lithium-Ion Battery
Running Speed :
20km/H
Wheel :
4 ( Insulated)
Charging Time :
8 Hours
Transport Package :
The Whole Cart Will Be Packed by Tarp.
Specification :
2000*2000*500
Trademark :
BETTER
Origin :
Xinxiang
HS Code :
84289090
Production Capacity :
50 Sets/Month
Description

Rail System Maintenance Vehicle Inspection Cart

Product Description


Introduction of Rail System Maintenance Vehicle Inspection Cart
The Rail System Maintenance Vehicle Inspection Cart is used for track inspections of railway or highway. Our clients use the electric track trolley transport people and their equipment for track maintenance.
We make a special design to make the inspection work safer and high-efficiency. Each part of the Electric Track Trolley is small enough to enable easy movement when the cart needs to leave the rail.

Characters
The Trolley adopts the lithium-ion battery as the power source. The car frame is welded by aluminum alloy which ensured that the self-weight is kept as low as possible. Only two people can lift the trolley from ground to the track. The speed of the car is controlled by the variable speed. The maximum flaw detection speed can be up to 20km/h. The wheels are insulted. For the seat, it's customized. You can choose two seats or four seats or more. All seats are with seatbelts. The seat can be detachable. Due to the high railway inspection works are carried out at night, this car is equipped with track lighting device.


Product Parameters
Model BXC-2t BXC-5t BXC-10t BXC-16t BXC-20t BXC-25t BXC-30t BXC-40t BXC-50t BXC-63t BXC-80t BXC-100t BXC-150t
Rated Load(t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size (mm) Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Height(H) 450 500 500 550 550 600 600 650 650 700 800 900 1200
Wheel Base(mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 270 270 300 350 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Total Power(kw) 2 3 2.2 2.2 2.2 3 3.5 4 5 6.3 8 10 15
Battery Capacity(Ah) 150 180 180 200 220 220 260 300 330 400 400 440 600
Battery Voltage(V) 48 48 48 48 48 48 48 48 48 48 72 72 72
Running Time When Full Load 4.32 5.4 4.8 4.3 4 4 3.5 3.6 3.3 3 3.6 3.2 2.9
Running Distance for One Charge(km) 6.5 8.1 7.2 5.1 4.8 4.8 4.2 4.3 4 3.6 4.3 3.8 3.2
Max Wheel Load(KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100 QU100

Structure
Motors: DC driving.
Gauge: Standard 1435mm (other gauges available)
Frame: Welded rectangular tube aluminum
Seats: 1/2/4/6, and can add towed trailer of the trolley.
Wheels: Aluminum and Insulation treatment.
Control: There are two driving wheels on the electric track trolley. One control box and one brake. The car such control button on the control box: forward and reverse switch, changing speed switch, battery voltage meter, low battery warning light, light switches and stop button.
Batteries: The lithium-ion battery has heavy duty and long service life, maintenance free, equipped with the battery case.
Chargers: You can charge the battery either on or off the electric track cart. When there is no power, 8 hours can be charged fully.


Our company
We design our special transfer cars for all kind of industries. We can manufacture them according to clients' specifications. For example, we can prepare them to be used in rails, with autonomous batteries or for special applications.
