Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Specifications
Brand Name :
BETTER
Model Number :
BDG
Place of Origin :
Xinxiang
MOQ :
1 Piece
Price :
US$3000-3500
Payment Terms :
L/C,T/T
Supply Ability :
50 Sets/Month
Delivery Time :
15-25 days
Packaging Details :
Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.
Product Name :
Battery-Power Transfer Cart
Usage :
Heavy Duty Material Transportation
Load Capacity :
1-300ton
Special Function :
Anti-Explosion,Heat-Resistant,Lifting,Customized
Material :
Steel
Transport Package :
The Whole Cart Will Be Packed by Tarp.
Specification :
2000*2000*500
Trademark :
BETTER
Origin :
Xinxiang
HS Code :
84289090
Production Capacity :
50 Sets/Month
Description
Battery Powered Rail Transfer Cart with Electrical Control System
This track transfer vehicle is powered by a large-capacity lithium battery and equipped with an intelligent electrical control system, specifically designed for heavy material handling on fixed tracks in factories, warehouses, and logistics centers.
Core Configuration
  • Load Capacity: Standard series from 5 to 150 tons with customization available
  • Power System: Lithium battery pack with 8-12 hour range, supports fast charging and battery swapping
  • Drive System: High-power AC variable-frequency or servo motors for smooth operation and precise control
  • Rail System: Compatible with QU70-QU120 heavy-duty rails with customizable track gauge
  • Control System: Intelligent electronic control for start, stop, speed regulation, and emergency braking
  • Control Method: Industrial-grade wireless remote control (standard) or vehicle-mounted wired control box (optional)
  • Platform Design: High-strength steel structure with anti-slip steel plates, T-shaped grooves, or special tool fittings
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Core Functions
  • Wireless Flexible Operation: Battery-powered design eliminates constraints of sliding contact lines and cable reels
  • Clean & Low-Noise: Pure electric drive with zero emissions and low operating noise
  • One-Click Operation: Intuitive remote control interface with quick start, stop, speed adjustment, and emergency stop
Safety Configuration
  • Operation Safety: Heavy-duty buffers, travel limit switches, and audible/visual alarm systems
  • Parking Safety: Dual protection with electromagnetic brakes and manual mechanical brakes
  • Remote Control Safety: Industrial-grade frequency hopping technology with automatic emergency braking on signal loss
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Product Parameters
Model BDG-2t BDG-5t BDG-10t BDG-16t BDG-20t BDG-25t BDG-30t BDG-40t BDG-50t BDG-63t BDG-80t BDG-100t BDG-150t
Rated Load (t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size L (mm) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Table Size W (mm) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Table Size H (mm) 450 450 500 550 550 600 600 650 650 700 800 900 1200
Wheel Base (mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 270 270 300 350 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Motor Power (kw) 0.8 0.8 1.5 2.2 2.5 3 4 5.5 5.5 7.5 7.5 11 15
Transformer Power (KVA) 3 3 5 6.8 6.8 6.8 10 10 10 20 20 30 30
Transformer Quantity 1 1 1 1 1 1 1 1 1 1 1 1 1
Running Distance (m) 70 70 70 70 70 70 70 60 50 50 50 50 50
Max Wheel Load (KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100 QU100
Applications
Suitable for various industrial scenarios requiring flexible, cable-free material transportation on fixed tracks:
  • Manufacturing workshops: Transferring large components, molds, engines, and gearboxes
  • Warehousing and logistics: Palletized goods transportation in heavy-duty shelving areas
  • Iron and non-ferrous metals: Transfer of steel coils, plates, and ingots
  • Heavy machinery manufacturing: Circulation of large structural components and equipment modules
  • Building materials: Transportation of prefabricated wall panels, floor slabs, beams and columns
  • Maintenance and repair workshops: Equipment movement across different areas
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Customization Options
  • Platform Customization: Flatbed, concave platform, V-shaped saddle, T-shaped slot platform, or platform with power rollers
  • Function Expansion: Hydraulic lifting, platform rotation, lateral movement, automatic weighing, RFID material identification, or automatic charging
  • Automation Upgrade: Multiple docking stations, production line PLC integration, laser navigation, AGV upgrade
  • Environmental Adaptability: Explosion-proof, high-temperature resistant, corrosion-resistant, and low-temperature versions
Frequently Asked Questions
What Are The Advantages of Using a Transfer Cart?
Transfer carts offer dedicated material handling for specific workplace activities, accommodate long loads through restrictive passageways, provide affordable heavy load handling, feature compact designs for limited floor areas, and offer customizable deck configurations.
What Product Handling Applications Use Transfer Carts?
  • Coils (V-Groove deck)
  • Tanks and uniformly distributed loads
  • Assemblies and fixture cradles for complete builds
  • Sub-assembly shuttle between production lines
  • Maintenance carts for motors and pumps
  • Equipment support with stand-off decking
  • Material shuttle for steel tubing
  • Elevating platforms for assembly processes
  • Sand casting with flat decking
How Can Transfer Carts Be Customized?
Please provide details about your specific requirements:
  • Type of load or product to be transferred
  • Weight of heaviest load
  • Dimensions (Length, Width, Height)
  • Trip time and frequency
  • Travel area specifications
  • Distance to travel
  • Other relevant operating conditions
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Our Advantages
  • Low Noise Operation: Minimal noise level for improved work environment
  • Maximum Safety: Comprehensive safety features for operators and materials
  • Easy Operation: User-friendly design with quick operator training
  • Easy Implementation: Operates on standard floors without complex installation
  • Versatile Capacity: Suitable for both small and extremely large loads up to 300 tons
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Packaging & Shipping
Our transfer carts are shipped according to size specifications:
  • Length < 6m, Width < 2.2m: 20ft container
  • Length 5.9m-12m: 40ft container
  • Multiple units: Full container loading
  • Single units: LCL Container shipping
  • Oversized dimensions: Flat rack or bulk cargo shipping
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
Certifications
Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling Battery Powered Rail Transfer Cart with Electrical Control System for and Safe Material Handling
