Specifications
Brand Name :
sino truck
Model Number :
ZZ3257N3447A
Place of Origin :
china
MOQ :
1 unit
Price :
usd32500.00 fob shanghai port per unit
Supply Ability :
20 units
Delivery Time :
10 working days
Packaging Details :
in nude
engine model :
WD615.69
horse power :
336hp
Dimension :
7125*2496*3600mm
Displacement :
9.726l
Description

stock new 336hp sino truck dumper truck

SPECIFICATION

VEHICLE SPECIFICATION DESCRIPTION
Type of Vehicle ZZ3257N3447A
Truck Type 6x4
Driving Position Left hand Driving
Truck weight 8680kg
G.V.W 25,000kg
Max speed(km/h) 75
Color Red
Chassis & Add Components
Frame Details High-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sub frame, all cold riveted cross members.
Dimension(Lx W xH)(unloaded)(mm) 7125*2496*3600
Approaching angle/Departure angle(°) 16/70
Overhang(front/rear) (mm) 1500/725
Wheel base (mm) 3425+1350
Engine
Model WD615.69
Power 336HP
Emission EURO II
Displacement(L) 9.726
Type water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection
Kind of Fuel Diesel
Clutch & Gear Box System
Clutch SINOTRUKΦ430mm diaphragm spring clutch
Gear Box HW19710 10 forwards and 2 reverse
Axles
Front Axle Model HF9 axle
Rear Axle HC16 axle
Electrical System
Battery 2X12V/165Ah
Alternator 28V-1500w
Starter 7.5Kw/24V
Brake System
Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Auxiliary brake Engine exhaust brake
Steering system
Model 8118
Type hydraulic steering with power assistance
Wheels & Tyres
Type 11.00R20
Brand Common Brand
Quantity 10+1 spare
Kin pin 90mm
Cabin
Type HW76 New cabin
Double sleeper, with air conditioner, all-steel forward control,55ºhydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers

other information do you need ,contact with us feel free.
