Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Specifications
Brand Name :
HAOBANG
Model Number :
1.2mm TPO waterproof membrane
Certification :
ISO
Place of Origin :
Shandong,China
MOQ :
1,000 square meters
Price :
Price negotiable
Payment Terms :
T/T,L/C
Supply Ability :
680000 square meters per year
Delivery Time :
6-7 work days
Packaging Details :
Packed in Roll and on Pallet
Application :
Roof
Design Style :
Traditional
Width :
1m/2m
Length :
20m/roll
Roofing Application :
Planted Roofs
Wind Uplift Resistance :
4.3 Kpa
Uv Resistance :
≥1500h
Port :
qingdao
Low Temperature Flexibility :
-40℃
Material :
Thermoplastic Polyolefin
Sample Request :
free
Transport Packages :
Tray Packaging
Description

Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs

Product Description



Product Name 1.2mm TPO Roofing Membrane (Smooth Version)
Material TPO
Color White


Composed of thermoplastic polyolefin (TPO), integrating the fusibility of propylene-alpha-olefin copolymer resins via cutting-edge polymerization techniques and the robustness of polypropylene resins, Haobang TPO-H is a uniform multi-layered composite thermoplastic polyolefin polymer waterproof sheet crafted by sophisticated processing methods, applied for the meticulous treatment of open rooftops.

Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal RoofsSuperior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs


Technical Data Sheet



GB27789-2011 TPO Waterproofing Membrane(Type H)
Tensile Properties

Value
Tensile strength ≥ MPa 12
Elongation at rapture
% 500
Dimensional change rate on heating
% 2
Low temperature bending
- -40℃No Cracks
Watertightness
- 0.3 MPa,2h Watertight
Impact resistance - - 0.5 kg ·m, No water leakage
Peel strength at joints
N/mm 4.0 or damaged
Right angle tear strength
N/mm 60
Water Absorption Rate(70℃168h)
% 4
Heat aging (115℃)


Time - h 672
Appearance - - No blistering,cracks,delamination,sticking or voids
Tensile strength retention ≥ % 90
Elongation retention at rapture ≥ % 90
Low temperature bendability - - -40, No Cracks
Chemical resistance


Appearance - - No blistering,cracksdelaminationsticking or voids
Tensile strength retention ≥ % 90
Elongation retention at rapture ≥ % 90
Low temperature bendability - - -40℃,No Cracks
Artificial climate accelerates aging


Time - h 2500
Appearance - - No blisteringcracks,delamination,sticking or voids
Tensile strength retention
% 90
Elongation retention at break ≥ % 90
Low temperature bendability

-40℃, No Cracks
Wind uplift resistance
4.3Kpa 90



Application


  • Transportation nodes: airport concourses, bullet train stations, bus terminals...​

  • Institutional edifices: trade fair complexes, galleries, arenas...​

  • Modern infrastructure: data hubs, distribution centers...​

  • Manufacturing facilities: automotive, semiconductor, engineering, cigar factories...​

Advantages


  • Outstanding fusibility;​

    Superb cold-weather malleability;​

    Superlative dimensional consistency;​

    Exceptional stretching ability;​

    Robust shock tolerance;​

    High solar reflectance;​

    Eco-conscious, reusable;​

    Sustained UV resilience

Specification



Every single standard roll is separately wrapped in polyethylene film. The width measures 2.0 meters, and the length is determined by the membrane's thickness.​
  • 0.8mm 30m (Approximate weight per roll: 48 - 50 kilograms)​
  • 1.2mm 25m (Approximate weight per roll: 62 - 64 kilograms)​
  • 1.5mm 20m (Approximate weight per roll: 62 - 64 kilograms)​
  • 1.8mm 15m (Approximate weight per roll: 56 - 58 kilograms)​
  • 2.0mm 15m (Approximate weight per roll: 62 - 64 kilograms)

Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs


Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs


Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs

FAQ



Q: Do you offer complimentary samples?​
A: Indeed, samples sized under 1M2 or weighing 1KG or less are provided without cost, but the buyer is responsible for covering the shipping fees.​
Q: Can I utilize my own logistics provider?​
A: Absolutely, we're happy to work with your designated shipping agent.​
Q: Is there room for price adjustment?​
A: Certainly, significant orders will receive a generous discount.
