Interlink Or Super Link Flatbed Semi Trailer 2 Axle 40 Ft Shipping Container Trailer With Lock

Specifications

Packaging Details :

Nude Packing

Brand Name :

Tourfine

Types of Suspension Systems :

Leaf Spring Suspension

MOQ :

Certification :

CE, ISO/TS16949

Model Number :

TFSL02

ABS Anti-lock Braking System :

ABS Anti-lock Braking System

Place of Origin :

China

Condition :

New

Price :

15000

Supply Ability :

3000 Per Month

Color :

Yellow, Red, Blue, White

Delivery Time :

30 work days

Specification :

carbon steel

Payment Terms :

L/C,T/T

Axle Brand :

Fuwa,Zy,BPW,Aq

Description

20FT Interlink Trailer with 40FT Flatbed Semi Trailer for Multi-Container Haulage

The 2 Axle 20FT Interlink Container Trailer combined with a 40FT Flatbed Semi Trailer is designed to provide a flexible and efficient solution for container transportation. Suitable for ports, logistics companies, freight operators, and long-distance cargo transportation, this trailer combination allows the safe movement of multiple container sizes while maximizing transport efficiency.

Equipped with high-quality container twist locks, the trailer securely accommodates 20FT and 40FT shipping containers, ensuring stability and safety during transit. The reinforced steel chassis offers excellent load-bearing capacity and durability, even under demanding road and operating conditions. Reliable axles, suspension systems, and braking components contribute to smooth performance and lower maintenance costs.

This interlink trailer solution is widely used in container logistics, port operations, and regional freight transportation, helping operators improve payload efficiency and reduce overall transportation costs.

Loading capacity	50T/60T
Size	Front :6150/620025001600mm
	Rear: 12250/1250025001600mm
Chassis (I beam)	Top flange plate	Material and thickness	12mm/14mm
	Bottom flange plate	Material and thickness	14mm/16mm
	Middle flange plate	Thickness	8mm/10mm
		Height	500mm
	Side beam height	Type	U steel
		Height	16# U steel
Floor	Material	Carbon steel Q235
	Thickness	3mm
	Floor type	Checkered plate
Running mechanism	Container twist lock	16 pcs in all
	Axle	Brand	FUWA/AQ/BPW/ZY
		Type	13t
		Number	4pcs
	Rim	Type	9.0-22.5
		Number	16 pcs
	Tire	Brand	Triangle brand
		Type	12R22.5/12.00R20/315/80R22.5
		Number	16pcs
	Suspension	Mechanical suspension
	Spring leaf	Leaf width	90mm
		Leaf thickness	13mm
		Layer/set	10 Layer
	King pin	Type	Bolts type
		Diameter	2 inch
	Brake system	Air tank	40L air tanks
		Brake chamber	6 double spring brake chamber
		ABS	Without
	Landing gear	Brand	JOST
		Type	Two speed 24t
Accessories	Spare tire carrier	2sets
	Light	LED light
	Voltage	24v
	Receptacle	7 ways
	Tool box	One piece,1000x500x500mm
	Paiting	Polyurethane paint&anti-rust primer&sand blasting
Tools for trailer	Head wrench ;spare wheel crank ; one fire extinguisher; Operation Manual

Interlink Or Super Link Flatbed Semi Trailer 2 Axle 40 Ft Shipping Container Trailer With Lock

Q1: What's your MOQ?
A: One unit.

Q2: What's your payment terms?
A: T/T or LC

Q3: How about the after sales service?
A: We provide technical support and spare parts for long life time of our products.Provide spare parts for the parts BY DHL,TNT,UPS OR FEDEX.

Q4: What is your shipping method?
A: Container, Flat rack container, Roro vessel, Bulk vessel

Q5: What is your delivery time?
A: It takes around 7 days to 60 days after receive the deposit

Q6.Can you satisfy my special requirement?
Sure! We can manufacture the trailers and trucks according to your requirement.

Q7: Do you offer good quality spare parts?
A:Yes.
