XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
Specifications
Packaging Details :
by Container
Price :
Negotiable
Model Number :
XC770K
Supply Ability :
1000 Per Month
Engine Brand :
Xichai
Delivery Time :
30 work days
Place of Origin :
China
Payment Terms :
L/C,T/T
Certification :
TUV, ISO
MOQ :
1
Bucket Capacity :
0.6
Operation Mode :
Pilot Hydraulic Control & Multi-Function Electroni
Brand Name :
XCMG
Operation Load :
3600kg/3700KG
Description

XC770K Heavy-Duty Skid Steer Loader with Quick Attachment System

Product Description


The XCMG XC770K Skid Steer Loader is a heavy-duty compact machine designed for construction, municipal maintenance, agriculture, and material handling applications. With a 1,250 kg rated operating capacity and a high-performance hydraulic system, it delivers reliable productivity in demanding working conditions.


Built with a reinforced chassis and an efficient quick attachment system, the XC770K skid steer loader can be equipped with buckets, pallet forks, sweepers, augers, hydraulic breakers, and many other attachments for multi-purpose operations. Its compact design provides excellent maneuverability in confined job sites, while the ergonomic operator cab improves comfort and visibility. Designed for durability, versatility, and low maintenance costs, this compact skid steer loader is an ideal solution for contractors, rental companies, farms, and industrial material handling.


Product Parameters
Main Parameters Unit XC740K XC750K XC760K XC770K
Rated Load kg 750 900 1080 1250
Tipping Load kg 1500 1800 2160 2500
Operating Weight kg 3080 3400 3450 3600/3700
Maximum Breakout Force kN ≥18 ≥20 22 22
Maximum Traction kN ≥20 ≥24 ≥26 ≥32
Hydraulic Flow Rate L/min 62.5 75.9 95 91.2
Optional High Flow L/min — 119.6 142.5 158.4
Hydraulic Pressure bar 200 210 210 210
Engine Model — Xinchai 4D27G31 Yanmar 4TNV98 Yanmar 4TNV98T Weichai WP4.1
Engine Power kW (HP) 36.8 (49.3) 50.2 (67.3) 61.3 (82.2) 74.9 (100.4)
Rated Speed rpm 2500 2400 2500 2400
Cooling Type — Liquid Liquid Liquid Liquid
Emission Standard — Stage III Stage III Stage III Stage III
Control System — Pilot Hydraulic + Electronic Pilot Hydraulic + Electronic Pilot Hydraulic + Electronic Pilot Hydraulic + Electronic
Tire Size — 10-16.5 10-16.5 12-16.5 12-16.5
Maximum Travel Speed km/h 14.3 13.5 12.5 11
Maximum Operating Height mm 3878 3878 4180 4180
Bucket Hinge Pin Height mm 3057 3057 3205 3205
Cabin Height mm 1950 1950 1960 1960
Maximum Bucket Bottom Height mm 2851 2851 2997 2997
Length Without Bucket mm 2533 2533 2660 3050
Length With Bucket mm 3320 3320 3610 3750
Maximum Dumping Height mm 2375 2375 2450 2450
Dumping Reach mm 575 575 570 570
Wheelbase mm 1027 1027 1188 1320
Ground Clearance mm 185 185 205 205
Turning Radius (Without Bucket) mm 1183 1183 1320 1370
Turning Radius (With Bucket) mm 2066 2066 2230 2230
Rear Turning Radius mm 1564 1564 1715 1840
Wheel Track mm 1380 1380 1500 1500
Bucket Width mm 1800 1800 2000 2000
Bucket Capacity m³ 0.45 0.45 0.6 0.6
Fuel Tank Capacity L 80 80 95 108
Hydraulic Oil Tank L 60 60 70 80
Detailed Photos

XC770K Heavy-Duty Skid Steer Loader with Quick Attachment SystemXC770K Heavy-Duty Skid Steer Loader with Quick Attachment SystemXC770K Heavy-Duty Skid Steer Loader with Quick Attachment SystemXC770K Heavy-Duty Skid Steer Loader with Quick Attachment System
  1. Q: What is the minimum order quantity (MOQ)?
    A: Our MOQ is one unit. We ensure every unit upholds the highest standards of quality and reliability.
  2. Q: What are your payment terms?
    A: We accept payment through T/T or LC, offering flexibility and security for your transactions.
  3. Q: What after-sales services do you provide?
    A: We provide comprehensive technical support and a robust supply of spare parts to ensure the long-term durability of our products. Spare parts can be shipped promptly via DHL, ***, UPS, or FedEx.
  4. Q: What shipping methods do you use?
    A: We utilize multiple shipping methods, including container, flat rack container, Roro vessel, and bulk vessel to ensure safe and efficient delivery.
  5. Q: How long does delivery take?
    A: Delivery time ranges from 7 to 30 days after receiving the deposit, depending on order volume and destination.
  6. Q: Can you accommodate special requirements?
    A: Absolutely! We specialize in manufacturing trailers and trucks tailored to your specific requirements.
  7. Q: Do you offer high-quality spare parts?
    A: Yes, we ensure the provision of high-quality spare parts to maintain the optimal performance of your equipment.
