80mm Max. Drilling Dia. Metal Processing Machine RD825 with 15000/11000kg Capacity
80mm Max. Drilling Dia. Metal Processing Machine RD825 with 15000/11000kg Capacity
80mm Max. Drilling Dia. Metal Processing Machine RD825 with 15000/11000kg Capacity
80mm Max. Drilling Dia. Metal Processing Machine RD825 with 15000/11000kg Capacity
Specifications
Condition :
New
type :
Radial Drilling Machine
Max. Drilling Dia. (mm) :
80
Range of Spindle Speed(r.p.m) :
16 - 1250 r.p.m
CNC or Not :
Normal
Drilling Speed :
16-1250 r.p.m
Place of Origin :
China
Brand Name :
TIMAC
Model Number :
RD825
Voltage :
As customer's request
Power (kW) :
7.5
Weight (KG) :
11000 KG
Warranty :
1 Year
Key Selling Points :
Competitive Price
Showroom Location :
United States, Italy, France, Brazil, Saudi Arabia, South Africa, Uzbekistan
Applicable Industries :
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Construction works , Energy & Mining
Marketing Type :
New Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Pump, Gear, Motor
drilling machine :
machine tools
Certification :
ISO9001; CE
Power :
7.5
Weight :
15000/11000kg
Packaging Details :
Veneer box or wooden case
Port :
China Port
Supply Ability :
65 Set/Sets per Month
Price :
$12,000.00/sets 1-2 sets
MOQ :
1 set
Description

80mm Drilling / Radial Drilling Machine For Metal Processing / RD825

80mm Max. Drilling Dia. Metal Processing Machine RD825 with 15000/11000kg Capacity

Feature:

Radial Drilling Machine For Metal Processing

1. The radial drilling machine is new series with diversified fuctions of product which has been designed and accomplished referring to international standard ISO in the recent years.

2. In this machine, hydraulic preselection speed and feed change mechanisms are adopted, the spindle head, radial arm and column are clamped by hydraulic clamping mechanisms.

3. The forward, reverse, stop(braking), as well as the setting of spindle in neutral position are all controlled by a single lever, the machine has characteristics features of perfect performance, safe, reliable and easy operation, convenient maintenance, high-accuracy, ample rigidity and long service long.

4. It is used for drilling, counter boring, spot facing, reaming, tapping and boring, widely used in every department of mechaninal machining.

Parameter:

Specification

RD620

RD825

Max.Drilling capacity (mm)

63

80

Distance spindle axis to column

generating line (mm)

450-2050

500-2500

Diameter of column (mm)

450

550

Spindle taper

MT5

MT6

Spindle travel (mm)

400

450

Spindle speeds range (r/min)

20-1600

16-1250

Spindle speeds steps

16

16

Range of Spindle feeds (mm/r)

0.04-3.2

0.04-3.2

Spindle feeds steps

16

16

Max.Distance spindle nose to working

surface of base (mm)

400-1600

550-2000

Dimension of worktable (mm)

960×630×500

1000×800×560

Dimension of base (mm)

2900×1250×250

3530×1400×300

Overall Size (mm)

3110×1250×3150

3730×1400×3790

Power of Main motor (KW)

5.5

7.5

G.W/N.W (kg)

8000/7000

15000/11000

Packing dimension (cm)

347×147×235

416×165×248

& 382×163×170
