7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart
Specifications
Brand Name :
ESEN
Model Number :
TX070IPS-2650RB-HDMI
Certification :
ISO9001/ISO14001
Place of Origin :
Shenzhen China
MOQ :
No MOQ
Price :
can be negotiated
Payment Terms :
L/C,T/T
Supply Ability :
300K/mth
Delivery Time :
6~14 working days
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
LCD Type :
7 inch
Dimensional outline :
163.8(W)x97(H)x2.6(D)
Active area :
154.2144(W)x 85.92(H)
Pixel size :
50.2(W)xRGBx143.2(H)
Resolution :
1024(RGB)x600
Luminance :
300~500cd/m2
Surface Treatment :
Glare
Display color :
16.7M
Viewing Direction :
IPS
Operating temperature :
-20--+70/-30--+85(℃)
Storage temperature :
-30--+80/-40--+90(℃)
Active Area(WxH) :
drawing
Backlight :
3*7-LEDs (white)
Data Transfer :
MIPI
Voltage :
2.8V to 3.3V
Interface :
I2C/USB
Custom Service :
FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board
Description

7.0 Inch 1024x600 LCD Touch Display MIPI Serial Port Interface IPS Smart LCD Display Module

This 7-inch IPS smart LCD module is very bright with a high resolution of 1024x600. It presents a reassuringly clear and lively image! The chip is powerful and the UART serial port is used for data transmission between devices. Touch operation is available with IPS technology featuring an ultra-wide viewing angle. It is applicable in industrial control, smart terminals and other fields, greatly enhancing the user experience.

Advantages

*UI design & hardware and software development
*Equipped with different STM32 main controller
*Support LINUX & RTOS system
*Excellent screen refresh rate
*Dynamic display effects

7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart7.0'' 1024 X 600 HDMI TFT LCD Display MIPI Serial Port Interface IPS Smart

  • FAQ:
    1.How can I find the right product?
    Please send us your requirements or datasheet, we will recommend our standard products, if it’s not fit, we will do the necessary adjustment & customization.
    2. Do you accept sample order or small quantity order?
    Yes, you can place sample orders for testing first, and small quantity order as pilot production (no less than MOQ)
    3. What are the payment terms?
    We usually accept T/T, Paypal, other terms to be negotiated.
    4.What’s the lead time?
    Usually 3~5 days for sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and particular product).
