ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface
ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface
ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface
ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface
ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface
ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface
Specifications
Brand Name :
ESEN
Model Number :
TX028-40RB-A2
Certification :
ISO9001/ISO14001
Place of Origin :
Shenzhen China
MOQ :
No MOQ
Price :
can be negotiated
Payment Terms :
L/C,T/T
Supply Ability :
300K/mth
Delivery Time :
6~14 working days
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
LCD size :
2.76 inch
Display Mode :
Normally Black
Resolution :
480(RGB)x480
Pixel pitch :
0.1497(H) x 0.1462(V)
Pixel Arrangement :
RGB Vertical Stripe
Viewing direction :
Free
Module outline dimension :
73.03 (H)*76.48 (V)*2.3(D)
LCD AA :
70.128 (H)* 70.128 (V)
TP VA :
--
Colors :
16.7M
Surface Lumiannce :
300/cd
Driver IC :
ST7701SN
Interface :
RGB
Backlight :
White LED
Operating Temperature :
-20℃~ +60℃
Storage Temperature :
-30℃~ +80℃
Custom Service :
FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board
Description

Key Features:

  • High Resolution: 480(RGB) x 480 pixels for sharp and vibrant visuals.
  • Compact Size: 2.8-inch display, ideal for compact and portable devices.
  • Wide Viewing Angle: Full 85° viewing angle in all directions (U/D/L/R) for versatile viewing.
  • Versatile Interface: Supports RGB 24-bit + 9b_3SPI interface for flexible connectivity.
  • Durable Performance: Operating temperature range from -30°C to +80°C.
  • Bright & Clear: 300 cd/m² brightness with LED backlight.

ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface

ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface

ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface

ST7701S Driver IC IPS TFT LCD Display 2.76 Inch 2.8 Inch 480x480 RGB Interface

Free Service:
1. Free Connectors for Sample Order.
2. 50% Discount for Tooling Charge.
3. Free Modification for Tooling of CTP / FPC / Backlight.
4. Free Tooling for Order ≥3000pcs Within 1 Year VIP.
5. Free Tooling for FPC.
6. Free Samples for Standard Products.
7. Free Testing Board for New Projects.
8. 8. Custom backlight/CTP mold fee.

FAQ

1.Q: Are you manufactory or trade company?
A: We are manufactory in China. Our factory located in Dongguan, and office located in Shenzhen
2.Q: How can I get the samples?
A: Send inquiry --Offer quotation --Confirm quotation & pay tooling charge -- Provide drawing -- confirm drawing -- make tooling & samples -- Samples finished -- Delivery via freight or sea colle.
3.Q: Can you design the lcd in acccordance with our demand?
A:Sure.We have professional team to meet all your demand.
4.Q:How to place orders ?
A:If you confirm samples ok, Please send us your purchase order by Email or Fax , Then we will send you an Invoice for deposit payment. We need to know the following information of your order.
1.Product information-Quantity,part number
2.Delivery time required.
3.Shipping information-Company name, Street address,Phone&Fax number,Destination sea port.
4.Forwarder's contact details if you have any in China.
5.Q:How long of mass production ?
A: 25-30 business days. It depends on different order quantities and part number.
