GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content，TY-14-3P-55-2001
Specifications
Brand Name :
YUHONG
Model Number :
GOST9941-81 12X18H12T
Certification :
ISO 9001/TUV/PED
Place of Origin :
China
MOQ :
500 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C at sight
Supply Ability :
1000 TONS / month
Delivery Time :
Depends on order quantity
Packaging Details :
Steel frame wooden case with plastic cap
Standard :
GOST9941-81
Material :
12X18H12T
Diameter :
3.18-152.4mm
Wall Thickness :
0.41mm - 25.4mm
Usage :
Heat exchanger tube, Boiler tube
Applications :
Boilers, heat exchangers, superheaters, HRSG
Description
GOST9941-81 12X18H12T Seamless Boiler Tube, Russian Standard, High Nickel Content,TY-14-3P-55-2001
GOST 9941-81 12X18H12T seamless pipe is a titanium-stabilized austenitic stainless steel seamless pipe under the Russian standard. It is widely used in chemical, power, and other fields requiring high-temperature and corrosive environments due to its excellent corrosion resistance and high-temperature resistance. Although this standard has been superseded by GOST 9941-2022, it is still widely recognized and used in actual trade and engineering.
Material grade: 12X18H12T. This is an austenitic grade stainless steel. Its core characteristic is the addition of titanium (Ti) as a stabilizing element to prevent intergranular corrosion during welding or high-temperature service.
Its international equivalent is mainly AISI 321, but there are significant differences. 12X18H12T has a nickel content as high as 11%, resulting in a much higher price in addition to performance differences.

GOST 9941-81 12X18H12T Chemical Composition (Mass Fraction, %)
Element Composition (% by weight)
Carbon (C) ≤ 0.12
Silicon (Si) ≤ 0.8
Manganese (Mn) ≤ 2.0
Chromium (Cr) 17.0 – 19.0
Nickel (Ni) 11.0 – 13.0
Titanium (Ti) 5×C% to 0.70
Sulfur (S) ≤ 0.020
Phosphorus (P) ≤ 0.035
Iron (Fe) Balance

GOST 9941-81 12X18H12T Mechanical Properties
Property Value
Tensile Strength (min.) ≥ 510 – 549 MPa
Yield Strength (0.2% offset, min.) ≥ 196 – 235 MPa
Elongation (min.) ≥ 35%
Heat Treatment Solution Anneal

Applications:

  • Chemical and Petroleum Industry: Widely used in the manufacture of heat exchangers, condensers, and reaction equipment, capable of withstanding various corrosive chemicals.
  • Power and Energy Sector: Used in steam boilers, power plant cooling systems, and some equipment in nuclear power plants, capable of operating continuously in a temperature range of -196°C to +600°C.
  • Marine Engineering: Used in the manufacture of marine heat exchangers and pipes, resistant to seawater corrosion.
  • Other Industries: Includes equipment in food processing, and water treatment industries requiring hygiene and corrosion resistance.
