Quick Locking Bolts Kit and Fixture Jigs for D28 D16 Welding Table
Quick Locking Bolts Kit And Fixture Jigs For D28 D16 Welding Table
Product Overview
The Quick Locking Bolts Kit and Fixture Jigs for D28 D16 Welding Table is a comprehensive set of core modular tooling accessories designed for three-dimensional flexible welding worktables. Specifically engineered for two standard hole system platforms - D16 (16mm) and D28 (28mm) - this system enables rapid positioning, precise clamping, and efficient locking of workpieces.
The innovative design features five concentric steel balls within the 28mm or 16mm quick locking pin body. When the locking pin thread is loosened, the steel balls automatically retract, allowing the pin to be easily inserted or removed from the workpiece round hole. During operation, the locking pin is inserted into the workpiece hole and the pin head is gradually tightened by hand, causing the steel balls to protrude and automatically lock into position.
Quick Locking Bolts Kit And Fixture Jigs For D28 D16 Welding Table
Product Specifications
Product Specifications Nominal Diameter (mm) Nominal Length (mm) Inventory (pieces)
D28 series M28 50 500
D28 series M28 75 500
D16 series M16 24 500
D16 series M16 36 500
Quick Locking Bolts Kit And Fixture Jigs For D28 D16 Welding Table
Key Features
  • Efficient Operation: Locking and loosening takes only 3-5 seconds, eliminating the need for repeated nut tightening
  • High Precision: Repeatable positioning accuracy of ±0.05mm ensures batch consistency
  • Flexible Configuration: Fully modular design allows any combination and rapid reconstruction to adapt to multiple workpiece types
  • Robust Performance: Large locking force and strong rigidity prevent deformation of heavy workpieces
  • Durable Construction: Industrial-grade materials provide impact resistance, welding heat resistance, and long service life
Manufacturer Advantages
  • Professional manufacturer specializing in 3D welding tables and modular clamping systems with independent R&D and production capabilities
  • Complete D16/D28 series quick locking bolts and fixture jigs offering one-stop solutions with stable quality
  • High-strength alloy steel materials with precision machining, quenching, and hardening for heavy-duty applications
  • Strict quality inspection processes ensuring high accuracy and long service life
  • In-stock standard parts with fast delivery, flexible minimum order quantities, and reliable after-sales support
  • Extensive export experience serving customers worldwide with professional service
Quick Locking Bolts Kit And Fixture Jigs For D28 D16 Welding Table
Buying Tips: We provide a variety of welding accessories. If you need other accessories or special customization, please contact us.
