Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Specifications
Other Name :
Cross welding manipulator
Certification :
CE
Duration :
20 days
Suitable tanks diameter :
700-3000mm
Monitor :
Optional
Payment Terms :
L/C,D/A,D/P,T/T,
Packaging Details :
Export standard package
Delivery Time :
20 days
Column effective stroke :
3000mm
Place of Origin :
China
MOQ :
1 set
Price :
500-10000usd
Welding :
Surbmerged arc welding/MIG welding
Supply Ability :
10 set/month
Brand Name :
Lemar
Optional :
Welding rotator or welding positioner
Trolley :
Optional
Model Number :
HJ3030
Boom effective stroke :
3000mm
Movable :
Yes or no/Customized
Description
HJ2020 Automatic Seam Welding Machine - Rotating TIG Arc Welding Manipulator with Electric Mobility
The HJ2020 Automatic Seam Welding Machine with Electric Mobile Welding Manipulator represents more than just conventional support equipment—it's a comprehensive automated welding solution specifically engineered for TIG welding applications. This system not only ensures precise welding torch movement but seamlessly integrates automation with process flexibility, significantly enhancing productivity.
Key Features & Capabilities
TIG-Optimized Design with Multi-Process Compatibility: Engineered specifically for stable TIG welding that produces aesthetically superior welds. Also compatible with conventional gas shielded welding, submerged arc welding, and other processes to accommodate diverse working conditions.
Extended 2m Boom for Enhanced Coverage: Features an effective travel range of 2m × 2m (vertical/horizontal). Constructed from high-strength rectangular steel tubing with vibration aging stress relief treatment for exceptional rigidity and minimal deformation.
Electric Movement with Precision Rail System: Standard configuration includes high-precision V-shaped or rectangular guide rails. Combined with mobile trolley system, it achieves smooth stepless electric speed control for long-distance movement along workshop rails, enabling straight seam welding of extra-long workpieces without repeated positioning adjustments.
Three-in-One Linkage for Compact Welding Workstation: Pre-installed integrated interface allows quick connection to welding roller frames (for circumferential welding of cylindrical bodies) or welding positioners (for complex angle welding). Enables automated operation where "the welding torch remains stationary while the workpiece moves, and vice versa."
Technical Specifications
Model HJ-2020
Column Effective Stroke 2000mm
Boom Effective Stroke 2000mm
Welding Source TIG/Submerged Arc Welding / MIG Welding
Trolley With or Without
Rotate Electric Type
Welding Tracking Customized
Voltage 380V or Customized
Other Optional Welding Positioner or Welding Rotator
Automatic Seam Welding Manipulator 2000mm Column And Boom For TIG
Have questions about the HJ2020 Automatic Seam Welding Machine? Our technical experts are ready to assist you with detailed specifications and application guidance.
