Specifications
Brand Name :
LEMAR
Model Number :
LW-C-M1201-030A2
Certification :
CE
Place of Origin :
WUXI
MOQ :
1
Price :
100-500 USD
Payment Terms :
,L/C,D/A,D/P,T/T,Western Union
Supply Ability :
500 units/month
Delivery Time :
15-25 work days
Packaging Details :
3000*2000*300mm
Noise level :
65–75 dB(A)
Applicable voltage :
220V / 380V / 415V optional
Protection level :
IP54 and above
Filtering methods :
Cartridge filtration
Dust collection method :
Drawer-type ash hopper
Installation method :
Mobile (with casters) / Fixed / Central
Body material :
24-hour continuous operation / Online dust cleaning without shutdown
Inhalation components :
360° omnidirectional flexible suction arm (can be hovered)
Cleaning method :
Pulse automatic backflushing dust removal
Description
Pulse Jet Cartridge Welding Fume Extractor for Continuous Operation
Industrial-grade fume purification device designed for high-load, uninterrupted welding operations. Features pulse backflushing technology for continuous 24/7 operation with automatic filter cleaning.
Technical Specifications
Air Volume 1500-10000 m³/h (customizable upon request)
Filtration Accuracy ≥99.9% @ 0.3μm
Backflush Pressure 0.6-0.8 MPa
Continuous Operation 24/7 uninterrupted
Noise Level ≤65-75 dB(A)
Filter Cartridge Life 8000-10000 hours
Emission Concentration ≤5 mg/m³ (better than national standard)
Pulse Jet Cartridge Laser Fume Extractor Continuous Portable Welding Fume Extractor Pulse Jet Cartridge Laser Fume Extractor Continuous Portable Welding Fume Extractor
Core Structure and Components
Filter Cartridge (Core)
PTFE-coated polyester filter media, MERV 15/16, filtration accuracy 0.1-0.3μm, single cartridge area 20-30㎡, lifespan 2-3 years / 8000 hours.
Pulse Backflush System
Pulse valve, air manifold, PLC/differential pressure controller, automatic/timed/differential pressure triggered backflush.
Fan Unit
Variable frequency centrifugal fan, stable air pressure, low noise, energy saving, suitable for 24-hour continuous operation.
Suction Arm/Hood
Flexible/omnidirectional/high temperature resistant, precise collection, suitable for manual/robotic welding.
Ash Collection System
Drawer-type/conical ash hopper, easy to clean, automatic ash discharge optional.
Electrical Control System
Differential pressure monitoring, overload protection, backflush sequence, variable frequency speed control, supports remote/linkage control.
Filter Media Performance
Polyester fiber membrane filter cartridge with smooth surface that prevents dust adhesion and facilitates easier cleaning. Waterproof and oil-proof, capable of handling welding fumes containing oil mist and moisture.
  • Filtration efficiency: ≥99.9% for 0.3μm dust particles
  • Service life: 8000-12000 hours under normal operating conditions
  • Replacement method: Side-mounted/top-mounted quick-release structure, tool-free, single-person operation
After-Sales Service and Support
  • Complete operating instructions and electrical schematics provided
  • Sufficient stock of vulnerable parts; global spare parts shipping
  • Video guidance for installation, commissioning, and maintenance
  • CE/CCC certification documents available
  • Hassle-free customs clearance and factory inspections
