ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering
ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering
ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering
ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering
Specifications
Brand Name :
SZ
Model Number :
Polyester Nonwoven Geotextile
Certification :
ISO/CE
Place of Origin :
China
MOQ :
20GP
Price :
$0.3-$2.0/SQM
Payment Terms :
L/C,D/P,T/T,Western Union,MoneyGram
Supply Ability :
8Ton Per Day
Delivery Time :
Withine 15 days
Packaging Details :
Roll By Woven Bags
Product Name :
500g Polyester Nonwoven Geotextile
Material :
Pure Polyester
Color :
White/Black/ Green
Length :
50-100 m
Type :
Nonwoven
Application :
Transportation Industry
CBR Burst Strength :
200-4000 N
Elongation :
25-100%
Width :
1-6 m
Weight :
100-800 g/m2
Description

Road Construction Geotextile Erosion Resistence Polyester Nonwoven Geotextiles For Civil Engineering Projects

Geotextiles are permeable geosynthetic materials made by needle-punched or woven synthetic fibers. The raw materials are PET or PP. Geotextiles comprise woven geotextiles and non-woven filament fiber geotextiles.

Advantage of Geotextile

✅Anti-aging the product has very high anti-ultraviolet radiation ability, not easy to degradation.

✅High temperature resistance up to 230℃ maintaining structure stability and original physical properties.

✅High flat drainage and vertical permeability.

✅High creep resistance.

✅Resistance of erosion of chemicals in soil with the corrosion of gasoline and diesel etc.

✅High elongation under certain stress, thus able to adapt to uneven and irregular bases.

ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil EngineeringASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering

Why Choose Our Nonwoven Geotextile?

1.Premium Material

  • 100% virgin polyester staple fiber

  • Needle-punched nonwoven structure

2.Performance Guaranteed

  • Meets ASTM D6241, ISO 9001 standards
  • 10+ years service life in harsh conditions

3.Global Project Support

  • 10+ countries served
  • MOQ 1x20' container (negotiable)

ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil EngineeringASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering

Technical Specifications

Unit weight

(g/sqm)

Thickness

(mm)

Breaking strength

(kn/m)

CBR burst strength(KN)

Elongation at break(%)

Tear Strength

(KN)
100 0.9 2.5 0.3 25-100 0.08
150 1.3 4.5 0.6 25-100 0.12
200 1.7 6.5 0.9 25-100 0.16
250 2.1 8.0 1.2 25-100 0.20
300 2.4 9.5 1.5 25-100 0.24
350 2.7 11.0 1.8 25-100 0.28
400 3.0 12.5 2.1 25-100 0.33
450 3.3 14.0 2.4 25-100 0.38
500 3.6 16.0 2.7 25-100 0.42
600 4.1 19.0 3.2 25-100 0.46
800 5.0 25.0 4.0 25-100 0.60

Project Applications

1. Road Construction

  • Separation & stabilization of subgrade

2. Landfill Systems

  • Leachate collection & protection layer

3. Drainage Systems

  • High-flow filtration in civil works

Certifications:

  • ISO 9001,ISO14001,ISO45001

  • CE Certified

ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering ASTM D6241 Polyester Nonwoven Geotextile Erosion Resistence For Civil Engineering
