200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction
200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction
200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction
200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction
Specifications
Brand Name :
SZ
Model Number :
Polyester Nonwoven Geotextile
Certification :
ISO/CE
Place of Origin :
China
MOQ :
20GP
Price :
$0.3-$2.0/SQM
Payment Terms :
L/C,D/P,T/T,Western Union,MoneyGram
Supply Ability :
8Ton Per Day
Delivery Time :
Withine 15 days
Packaging Details :
Roll By Woven Bags
Product Name :
Polyester Nonwoven Geotextile
Material :
Pure Polyester
Color :
White or Black
Length :
50-100 m
Type :
Nonwoven
Application :
Dam And Road Construction
CBR Burst Strength :
200-4000 N
Elongation :
25-100%
Width :
1-6 m
Weight :
100-800 g/m2
Description

Good Permeability Polyester Nonwoven Geotextiles For Dam And Road Construction

Description:

The non woven geotextiles are made by non-woven process technology, selects polyester staple fiber with high monofilament strength and excellent thickness ratio as raw material after underwent adequate scutching.

The state-of-the-art high speed needle punching production line is adopted, its roll width is up to 8meters.

Properties:

It is of excellent physical and hydraulic properties, and especially its advantages in the tensile strength, longitudinal and lateral strength ratio, uniformity and so on.

Supply a wide range of color, such as white, green and grey. Independent developed soft green fiber can protect installer’s eyes at the onsite during work under the strong light, and it is eco-friendly productions.

Type(mass per unit area): 200g/m2, 250g/m2, 300g/m2, 350g/m2, 400g/m2, 450g/m2, 500g/m2, 600g/m2, 800g/m2

200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction

Why Choose Our Nonwoven Geotextile?

1.Premium Material

  • 100% virgin polyester staple fiber

  • Needle-punched nonwoven structure

2.Performance Guaranteed

  • Meets ASTM D6241, ISO 9001 standards
  • 10+ years service life in harsh conditions

3.Global Project Support

  • 10+ countries served
  • MOQ 1x20' container (negotiable)

200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction

200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction

Technical Specifications

Type

　

SZGT200

SZGT250

SZGT300

SZGT350

SZGT400

SZGT450

SZGT500

SZGT600

SZGT800

mass per unit area

g/sqm

200

250

300

350

400

450

500

600

800

thickness, min.

mm

1.7

2.1

2.4

2.7

3.0

3.3

3.6

4.1

5.0

tensile strength at break(MD/CMD), min.

kN/m

6.5

8.0

9.5

11.0

12.5

14.0

16.0

19.0

25.0

elongation at break(MD/CMD)

%

25~100

tear strength(MD/CMD), min.

kN

0.16

0.20

0.24

0.28

0.33

0.38

0.42

0.46

0.60

CBR puncture resistance, min.

kN

0.9

1.2

1.5

1.8

2.1

2.4

2.7

3.2

4.0

apparent opening size(O90)

mm

0.06~0.20

vertical permeability coefficient

cm/s

(1.0~9.9)x(10-1~10-3)

roll width

m

8.0

Project Applications

1. Road Construction

  • Separation & stabilization of subgrade

2. Landfill Systems

  • Leachate collection & protection layer

3. Drainage Systems

  • High-flow filtration in civil works

Certifications:

  • ISO 9001,ISO14001,ISO45001

  • CE Certified

200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction 200g/M2 250g/M2 Nonwoven Polyester Geotextile For Dam And Road Construction
