Specifications
Place of Origin :
Anhui, China
Model Number :
SUN-75K-G01P3-EU-AM8-LV
Brand Name :
Deye
Input Voltage :
800
Output Voltage :
120V/208V, 127V/220V, 133V/230V
Output Current :
157.5/150.4A-196.9/188A
Output Frequency :
50/60Hz
Output Type :
Three Phase
Size :
1006x516x325.5mm
Type :
DC/AC Inverters
Inverter Efficiency :
98.8%
Weight :
103 kg
Product name :
Deye Three Phase String Inverter (LV)
External Temperature Sensor :
Yes
Application :
Residential
Inverter type :
On grid String inverter
Start-up Voltage (V) :
250
MPPT Voltage Range (V) :
200-700
Protection :
IP65
Color :
White
MOQ :
2 pieces
Price :
$1,650-1,680 / piece
Description
Product Description
Deye Three Phase String Inverter SUN-75K-G01P3-EU-AM8-LV Low Voltage 75kW Deye On-Grid Solar Inverters



DEYE


SUN-60/70/75K-G01P3-EU-AM8-LV

Three Phase String Inverter(LV)
Deye Three Phase String Inverter SUN-75K-G01P3-EU-AM8-LV Low Voltage 75kW Deye On-Grid Solar Inverters



120V/208V, 127V/220V, 133V/230V and
50/60Hz, Three phase system

8 MPP trackers, Max. efficiency up to 98.8%
Deye Three Phase String Inverter SUN-75K-G01P3-EU-AM8-LV Low Voltage 75kW Deye On-Grid Solar Inverters
Deye Three Phase String Inverter SUN-75K-G01P3-EU-AM8-LV Low Voltage 75kW Deye On-Grid Solar Inverters
Specification
Model
SUN-60K-G01P3-EU-AM8-LV
SUN-70K-G01P3-EU-AM8-LV
SUN-75K-G01P3-EU-AM8-LV
Input Side
Max. DC Input Power (kW)
90
105
112.5
Max. DC Input Voltage (V)
800
Start-up DC Input Voltage (V)
250
MPPT Operating Range (V)
200-700
Max. DC Input Current (A)
40+40+40+40+40+40+40+40
Max. Short Circuit Current (A)
60+60+60+60+60+60+60+60
No.of MPP Trackers
8
No.of Strings per MPP Tracker
4+4+4+4+4+4+4+4
Output Side
Rated Output Power (kW)
60
70
75
Max. Active Power (kW)
60
70
75
Rated Output Voltage/Range (V)
3L/N/PE 120V/208V, 127V/220V, 133V/230V 0.85Un-1.1Un (this may vary with grid standards)
Rated Grid Frequency (Hz)
60Hz/55Hz-65Hz, 50Hz/45Hz-55Hz
Operating Phase
Three Phase
Rated AC Grid Output Current (A)
157.5/150.4
183.8/175.5
196.9/188
Max. AC Output Current (A)
157.5/150.4
183.8/175.5
196.9/188
Output Power Factor
0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi)
<3%
DC Injection Current (mA)
<0.5%
Efficiency
Max. Efficiency
98.8%
Euro Efficiency
98.3%
MPPT Efficiency
>99%
Protection
DC Reverse-Polarity Protection
Yes
AC Short Circuit Protection
Yes
AC Output Overcurrent Protection
Yes
Output Overvoltage Protection
Yes
Insulation Resistance Protection
Yes
Ground Fault Monitoring
Yes
Anti-islanding Protection
Yes
Temperature Protection
Yes
Integrated DC Switch
Yes
Remote Software upload
Yes
Remote Change of Operating Parameters
Yes
Surge Protection
DC Type II / AC Type II
General Data
Cabinet Size (WxHxD mm)
1006×516×325.5 (Excluding Connectors and Brackets)
Weight (kg)
103
Topology
Transformerless
Internal Consumption
<1W (Night)
Running Temperature
-25-60℃, >45℃ Derating
Ingress Protection
IP65
Noise Emission (Typical)
≤65 dB
Cooling Concept
Smart Cooling
Permissible Altitude (m)
4000
Warranty
5 Years
Grid Connection Standard
NBR 16149, NBR 16150, EN 50549, RD 140
Operating Surroundings Humidity
0-100%
Safety EMC / Standard
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Features
Display
LCD 240 × 160
Interface
RS485/RS232/Wifi/LAN
