| Model | DQS13 | Unit |
|---|---|---|
| Boundary Dimension(l'*h*w) | 1550*1060*1340 | mm |
| Packaging dimension(l*h*w) | 1620*1080*1410 | mm |
| Cleaning Width | 1300 | mm |
| Maximum efficiency | 8800 | m2/H |
| Cleaning efficiency | 98 | % |
| Front drive Power | 650 | W |
| Power | 1800 | W |
| Running speed | 6.8 | Km/h |
| Backward speed | 2.6 | |
| Filtering area | 6 | ㎡ |
| Turning radius | 1200 | mm |
| Bin Capacity | 100 | L |
| Main brush width | 650 | mm |
| Side brush diameter | 500*2 | mm |
| Tank capacity | 40 | L |
| Maximum cleaning particle | 50 | mm |
| Continuous working hours | 5 | H |
| Total weight(including battery) | 362 | kg |
| Climbing cability | ≤15 | % |
| Lead-acid battery(standard) | 24V150AH | - |
| Lithium battery(optional) | 25.6V150AH | - |
| Charging time | 8-10 | H |
1.Suitable for cleaning peel paper scraps, stones and other visible solid,garbage,as well as the right amount of dust. To the construction site,the mine field and so on,the dust primarily sweeps the ability to be relatively poor.
2.Clean the filter regularly to ensure effective dust control.
3.Avoid wet,slippery and wet surfaces. Dirt may accumulate before the main brush,need clean frequently.
4.The brush pressure should not be too low,or affect the cleaning effect,resulting in ineffective brush wear.
Mainly widely applicable to various outdoor large-area open sites and semi-open industrial sites, including industrial parks, logistics yards, outdoor parking lots, urban squares, commercial plazas, factory peripheral areas, port terminals, scenic spots, school campuses, property communities and construction sites.
The machine’s excellent terrain adaptability and large-area cleaning capacity make it the ideal cleaning equipment for industrial, municipal, commercial and property management scenarios.
