| Model | DQS19B | Unit |
|---|---|---|
| Boundary Dimension(l'*h*w) | 2340*1790*2030 | mm |
| Packaging dimension(l*h*w) | 2315*1470*2190 | mm |
| Cleaning Width | 1950 | mm |
| Maximum efficiency | 14000 | m2/H |
| Cleaning efficiency | 97 | % |
| Front drive Power | 3000 | W |
| Power | 5700 | W |
| Running speed | 9.5/7.5 | Km/h |
| Backward speed | 5 | |
| Filtering area | 6 | ㎡ |
| Turning radius | 2300 | mm |
| Bin Capacity | 200 | L |
| Main brush width | 800 | mm |
| Side brush diameter | 550*2+500*2 | mm |
| Tank capacity | 50 | L |
| Maximum cleaning particle | 60 | mm |
| Continuous working hours | 4.5-6 | H |
| Total weight(including battery) | 810 | kg |
| Climbing cability | ≤30 | % |
| Lead-acid battery(standard) | 48V180AH | - |
| Charging time | 8-10 | H |
| Lithium battery(optional) | 48V200AH | - |
1. Real-time start the dust-scraping button,and regularly clean the filter manually to ensure effective dust control.
2. Avoid cleaning wet and wet ground,the main brush before easy accumulation of soil,need to be cleaned frequently.
3. The brush pressure should not be too low,or affect the cleaning effect,resulting in ineffective brush wear.
Mainly widely applicable to various outdoor large-area open sites and semi-open industrial sites, including industrial parks, logistics yards, outdoor parking lots, urban squares, commercial plazas, factory peripheral areas, port terminals, scenic spots, school campuses, property communities and construction sites.
The machine’s excellent terrain adaptability and large-area cleaning capacity make it the ideal cleaning equipment for industrial, municipal, commercial and property management scenarios.
