1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
Specifications
Classification :
Type 1+Type 2
Ucpv :
1000V
Up :
≤4.0kV
tA :
≤25ns
Product name :
DC SPD Type 1
In :
20kA
Mounting on :
35mm Din rail
Iimp :
12.5kA
Brand Name :
BRITEC
Model Number :
BRPV3-1000 T1
Certification :
CE TUV CB
Place of Origin :
China
MOQ :
20 piece / pieces
Payment Terms :
T/T,L/C,D/A
Supply Ability :
50000 pieces per month
Delivery Time :
15-20 days after payment
Packaging Details :
EXPORT PACKING
Test standards :
EN61643-31 / EN50539-11
Tu :
-40℃...+80℃
Shipping term :
TNT DHL FEDEX EMS UPS
OEM/ODM :
Available
Description
BRPV3-1000 T1 50ka DC 1000V 12.5ka PV Surge Arrester - Solar Surge Protection Device
Product Overview

12.5kA Solar PV 20KA-50ka DC 1000V surge protector surge protection SPD. Like all outdoor structures, PV installations are exposed to the risk of lightning which varies from region to region. Preventive and arrest systems and devices should be in place.

  • Type 1+2 surge protector for photovoltaic systems
  • Lightning impulse current (10/350us): 12.5kA
  • Max. continuous operating DC voltage: 1000V DC
  • EN61643-31 and EN50539-11 compliance
Technical Specifications
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
ParameterSpecification
SPD classification according to EN61643-31Type 1+Type 2
SPD classification according to EN50539-11Class I+Class II
Max. continuous operating DC voltage Ucpv1000V
Lightning impulse current (10/350us) Iimp12.5kA
Nominal discharge current (8/20us) In20kA
Max. discharge current (8/20us) Imax50kA
Voltage protection level [(DC+/DC-)->PE] Up≤4.0kV
Response time tA≤25ns
Operating temperature range Tu-40℃ to +80℃
Operating state / fault indicationGreen / Red
Cross-section area (Min.)4mm²
Cross-section area (Max.)35mm²
For mounting on35mm Din rail
Enclosure materialThermoplastic UL94-V0
Degree of protectionIP20
Dimensions
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
Applications
  • For use in photovoltaic power supply systems up to 1000 V DC
  • Protect against lightning surge voltages in photovoltaic power supply network
  • Protect sensitive electronic equipment from destructive transient over voltages originating from lightning strikes and electrical disturbances
  • Utilized in protecting photovoltaic systems against both direct and indirect lightning discharges
Key Advantages
  • Improved life expectancy
  • Optical status indicator via LED
  • Space-saving enclosure with a width of only four modules for up to 1000 V DC
  • Operating state / fault indication by green / red indicator flag in the inspection window
Our Services
  • 25 years global leading profession manufacture of electrical products surge arrester
  • All products will be well packed before shipping
  • Standard packaging, with custom packaging options available
  • Faster delivery times
  • Individually tested prior to shipment
Why Surge Protection is Essential

Large single surge events, such as lightning, can reach hundreds of thousands of volts and can cause immediate or intermittent equipment failure. Although these surges may be smaller in magnitude, they occur more frequently and with continuous exposure can degrade sensitive electronic equipment within the facility. The use of adapted surge protections is then highly recommended.

Installation Instructions
  • Mount the SPD on 35 mm DIN rail
  • The SPD is placed in parallel between the energized conductors and ground
  • The selected SPD must be specifically designed, rated and approved for application on DC PV voltages
Company Profile

Wenzhou Britec Electric Co., Ltd. is a manufacturer and exporter specialized in SPDs, including AC surge protectors, DC surge protection, LED lighting surge arresters, data surge protective devices and more. Located in Yueqing, Zhejiang, China, we offer convenient transportation, excellent quality and prices, and superior service that attracts customers worldwide.

Our company maintains ISO9001, ISO45001, and ISO14001 management systems. Various products are TUV, CB CE, RoHS certified. Our company culture is "sincere and trustworthy, punctuality, high-quality" - welcome every client!

1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company 1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company 1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company 1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
Certifications

The company carries ISO9001, ISO45001 , ISO14001 management system. Various products are TUV, CB CE, RoHS, certified.

1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
Payment Terms
Payment TermTerms
T/T | EXW30% T/T in advance, paid the balance before shipment
FOB | CIF30% T/T in advance, paid the balance against copy of B/L
L/CL/C amount above 50,000 USD, we can accept L/C at sight
PaypalAmount lower than 5000 USD
Delivery Time15-30 days after receiving deposit
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
Our Factory
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company 1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
Frequently Asked Questions
Q1: How long is your products warranty?
A: The warranty period of our products is 5 Years.
Q2: How about inspection?
A: We have the whole inspection system from raw material to end products.
Q3: What is the service offered by company?
A: We have the professional engineer team which can design and develop the mold to arrive different customer requirement. We also have the sales team to offer good service from pre-sale to after-sale.
1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company 1000V DC 12.5kA Lightning Impulse Type 1+2 Photovoltaic SPD Solar Surge Arrester DC SPD Type 1 SPD Company
