Specifications
Brand Name :
PAEKER
Model Number :
NV55 Series High Flow Diaphragm Valves
Place of Origin :
china
MOQ :
2
Price :
$158
Payment Terms :
T/T
Supply Ability :
>10
Body Style :
2-Way
Trim Material :
Stainless Steel
Material :
Stainless Steel
Actuation :
Manual
Size :
1/4
Application :
Industrial
Product Type :
Control Valve
End Connection :
NPT
Pressure Rating :
6000 psi
Seal Material :
PTFE
Temperature Range :
0-200°F
Flow Coefficient :
0.5
Media :
Gas
Description

Product Description:

NV55 Diaphragm Valve: Economical, High - Flow Solution for Versatile Fluid Handling Looking for a reliable valve for fluid management, The NV55 diaphragm valve is your answer. It's an economical and general - purpose option, perfect for high - flow applications where large volumes of both corrosive and non - corrosive fluids are in play. Constructed from durable 316L stainless steel, this compact valve guarantees positive and consistent shut - off, whether manually or air - actuated. This feature ensures safety and efficient operation in various industrial setups. The NV55 comes with an Elgiloy® diaphragm, enhancing its performance and longevity. Plus, its metal - to - metal seal to the atmosphere provides excellent leak integrity, reducing the risk of fluid leakage. Ideal for chemical processing, water treatment, and other industries, the NV55 offers a cost - effective yet high - quality solution for fluid handling needs.

Product Features:

• Internally threadless and springless

• High cycle life

• Compact size

• Positive, consistent shut off

• Metal to metal seal to atmosphere

• Ideal for high flow applications

• Fully functional from vacuum to 125 psig for AOPLPNO valves / 250 psig for manual and AOPLPNC valves

Specifications:

Parameter Details
Operating Conditions
Maximum operating pressure - AOP 125 psig (8.6 barg)
Maximum operating pressure - Manual 250 psig (17.2 barg)
Minimum operating pressure Vacuum
Actuator pressure 70 - 125 psig (4.8 - 8.6 barg)
Temperature -15°F to 150°F (-26°C to 66°C)
Bake out in the open position 250°F (121°C)
Design Proof Pressure 375 psig (26 barg)
Design Burst Pressure 750 psig (52 barg)
Functional Performance - Standard Connections 1/4" Compression, Male NPT, Female NPT
3/8" Compression, Male NPT, Female NPT
1/2" Compression, Male NPT, Female NPT
Internal Volume 3.29cc
Approximate Weight 0.81 lbs (0.36 kgm)

Product Details:

Industrial NV55 Series High Flow Diaphragm Valves For Fluid ManagementIndustrial NV55 Series High Flow Diaphragm Valves For Fluid Management
