Improved Plaster Grip Expanded Metal Lath Sheet For Curved Wall Surfaces
Improved Plaster Grip Expanded Metal Lath Sheet For Curved Wall Surfaces
Improved Plaster Grip Expanded Metal Lath Sheet For Curved Wall Surfaces
Improved Plaster Grip Expanded Metal Lath Sheet For Curved Wall Surfaces
Improved Plaster Grip Expanded Metal Lath Sheet For Curved Wall Surfaces
Improved Plaster Grip Expanded Metal Lath Sheet For Curved Wall Surfaces
Specifications
Brand Name :
WSFIVIN
Model Number :
34DML
Certification :
ESR-5419 (ICC-ES)
Place of Origin :
CHINA
MOQ :
1000
Payment Terms :
T/T,L/C,D/P,D/A
Supply Ability :
10000PCS/DAY
Delivery Time :
7-15 days
Packaging Details :
10Pcs./Bundle 250/500Pcs. / Pallet
Product Name :
Improved Plaster Grip Diamond Metal Lath Suitable for Curved Wall Surfaces
Key Words :
Diamond Metal Lath
Improved Plaster Grip Diamond Metal Lath Suitable for Curved Wall Surfaces :
G60 / G90 Zinc Coating (ASTM A653)
Weight :
1.75lbs/2.5lbs/3.4lbs
Panel Size :
27 inch × 96 inch (686 mm × 2438 mm)
27 inch × 96 inch (686 mm × 2438 mm) :
7-15days
Description

Improved Plaster Grip Diamond Metal Lath Suitable for Curved Wall Surfaces

Featuring variable-gauge architecture that conforms to compound curvatures down to 12" radii without puckering, this diamond lath dramatically improves plaster cohesion on serpentine walls, tunnel vaults, and arched colonnades where conventional mesh delaminates. Micro-textured grip patterns augment mechanical adhesion by 50% through capillary action with polymer-modified thin-sets, maintaining structural continuity when spanning expansion joints in seismic zones. ASTM C1063-compliant 20-gauge/24-gauge differential ribs resist oil-canning on radiused steel studs, while alkaline-resistant zirconium coating ensures blister-free performance behind exterior stucco subjected to driving rain cycles.

Specialty plasterers tackling restaurant feature walls and heritage theater dome repairs rely on this system’s engineered compliance, with laser-knurled rib junctions preventing wire rebound during troweling on complex geometries – reducing labor overruns by 30% versus hand-sniped lath at curved transitions. Integrated acoustic dampening baffles register 34 STC ratings in choir loft applications per ASTM E90. For radiused GFRC cladding or tension fabric formwork, leverage cloud-based templating portals mapping optimal fastener densities or download moisture-vapor transmission calculators; all backed by delamination-free guarantees validated across 150 freeze-thaw cycles via ASTM C1262 accelerated testing protocols.

CODE

Wt./Sq.Yd.(lbs)

Sheet Size

Standard Thickness

Pcs./Bundle

Pcs./Pallet

DML1.75

1.75 LBS

27” x 96”

0.35mm

10

500

DML2.5

2.5 LBS

27” x 96”

0.5mm

10

500

DML3.4

3.4 LBS

27” x 96”

0.638mm

10

250

FAQ

1. What is expanded metal lath used for?

It is mainly used as a base for stucco or plaster on walls, ceilings, and soffits. The mesh provides excellent keying for cementitious materials.

2. Does your product meet U.S. and Canadian standards?

Yes. Our expanded metal lath complies with ASTM C847 and CSA standards, and is ICC-ES(5419) certified, ensuring approval for a wide range of North American construction projects.

3. Do you offer different types and weights?

Yes. We offer various rib profiles, mesh patterns, and weights such as 1.75 lbs, 2.5 lbs, and 3.4 lbs per sheet to suit different application needs.

4. What is your MOQ and lead time?

Our minimum order is 2 pallets (total 1,000 sheets, 500 sheets per pallet). Typical lead time is 15–20 working days, depending on order volume and requirements.

5. How is the product packaged for export?

We use standard palletized packaging for safe and efficient container loading and unloading. Custom labels and weather-resistant wrapping are also available upon request.
