High Load Capacity Galvanized Stucco Mesh G60 Expandable Metal Lath
High Load Capacity Galvanized Stucco Mesh G60 Expandable Metal Lath
High Load Capacity Galvanized Stucco Mesh G60 Expandable Metal Lath
High Load Capacity Galvanized Stucco Mesh G60 Expandable Metal Lath
High Load Capacity Galvanized Stucco Mesh G60 Expandable Metal Lath
High Load Capacity Galvanized Stucco Mesh G60 Expandable Metal Lath
Specifications
Brand Name :
WSFIVIN
Model Number :
1.75DML
Certification :
ESR-5419 (ICC-ES)
Place of Origin :
CHINA
MOQ :
1000
Payment Terms :
T/T,L/C,D/P,D/A
Supply Ability :
10000PCS/DAY
Delivery Time :
7-15 days
Packaging Details :
10Pcs./Bundle 250/500Pcs. / Pallet
Product Name :
High Load Capacity Diamond Metal Lath G60 Galvanized
Key Words :
Diamond Metal Lath
Usage :
Interior and Exterior Walls, Ceilings, and Floors
Matarial :
Galvanized Sheet
Application :
Plastering and Stucco Work
Packing :
Pallet or Carton
Description

High Load Capacity Diamond Metal Lath G60 Galvanized

Engineered for extreme structural demands, this high-load-capacity diamond mesh lath features commercial-grade G60 galvanization to withstand seismic loads and multi-story dead weights while preventing substrate cracks through rigid reinforcement. The densely packed steel strands form a durable three-dimensional matrix, optimizing mechanical keying for plaster/mortar adhesion across heavy-duty partitions and horizontal assemblies. Standardized 27"x96" panels coupled with hot-dipped zinc protection deliver uncompromising corrosion resistance—suitable for coastal high-rises, industrial plants, and infrastructure projects demanding lifetimes of service.

Structural engineers and concrete contractors specify this ASTM C1063 & ICC-ES approved lath for elevator shafts, tilt-up construction, ICF systems, and fire-rated assemblies (ASTM E119) across Canadian and U.S. building sectors. Distributors reduce inventory costs via stackable pallet configurations (±480 panels), while G60's anti-spalling properties accelerate installation in challenging environments—cutting rework by 35%. Partner with our fabrication specialists for site-specific coil widths or perforation patterns, backed by just-in-time logistics support for stadiums, hospitals, and critical facilities where structural integrity is non-negotiable.

CODE

Wt./Sq.Yd.(lbs)

Sheet Size

Standard Thickness

Pcs./Bundle

Pcs./Pallet

DML1.75

1.75 LBS

27” x 96”

0.35mm

10

500

DML2.5

2.5 LBS

27” x 96”

0.5mm

10

500

DML3.4

3.4 LBS

27” x 96”

0.638mm

10

250

FAQ

1. What is expanded metal lath used for?

It is mainly used as a base for stucco or plaster on walls, ceilings, and soffits. The mesh provides excellent keying for cementitious materials.

2. Does your product meet U.S. and Canadian standards?

Yes. Our expanded metal lath complies with ASTM C847 and CSA standards, and is ICC-ES(5419) certified, ensuring approval for a wide range of North American construction projects.

3. Do you offer different types and weights?

Yes. We offer various rib profiles, mesh patterns, and weights such as 1.75 lbs, 2.5 lbs, and 3.4 lbs per sheet to suit different application needs.

4. What is your MOQ and lead time?

Our minimum order is 2 pallets (total 1,000 sheets, 500 sheets per pallet). Typical lead time is 15–20 working days, depending on order volume and requirements.

5. How is the product packaged for export?

We use standard palletized packaging for safe and efficient container loading and unloading. Custom labels and weather-resistant wrapping are also available upon request.
