8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
Specifications
Material :
steel
Product Type :
Wire Rope
Tensile Strength :
1370/1770N/mm²、1570/1770N/mm²、1770N/mm²
Nominal Diameter :
6 mm
Number Of Wires Per Strand :
19
Number Of Outer Wires :
8 strands
Construction :
8×19S+8×7+PP
Surface Treatment :
ungalvanized
Implementation standard :
ISO 4344/ EN 12385-4
Application Fields :
Elevator Industry、Lifting and Hoisting Operations、Mechanical Transmission
Brand Name :
Huayi
Model Number :
8×19S+8×7+PP
Place of Origin :
China
MOQ :
2000m
Payment Terms :
T/T,L/C
Supply Ability :
10000+M+
Description
8x19S+8x7+PP - 6 Elevator Steel Rope
8×19S+8×7+PP Construction 6 mm Nominal Diameter Elevator Steel Rope with 1570/1770N/mm² Tensile Strength
Product Overview

The 8×19S+8×7+PP 1570 elevator steel rope is engineered for demanding lifting applications with its specialized construction and high-performance characteristics.

Structural Composition
Strand Configuration

"8×19S" indicates 8 strands with 19 wires each in Seale construction, featuring thick outer wires for superior abrasion resistance.

Additional Strands

"8×7" represents 8 additional strands, each containing 7 wires, contributing to the rope's overall strength and flexibility.

Core Material

"PP" denotes polypropylene fiber core, providing excellent flexibility, lubrication retention, and anti-extrusion capabilities.

Performance Characteristics
  • High Strength & Abrasion Resistance: Thick outer wires provide exceptional durability when contacting pulleys and components
  • Superior Flexibility: Maintains strength while adapting flexibly during bending and winding operations
  • Shock Absorption: Fiber core acts as internal buffer, reducing vibrations from impact loads
  • Continuous Lubrication: Fiber core stores lubricating oil, reducing internal friction and preventing rust
  • Chemical Stability: Polypropylene core enhances overall performance with excellent chemical resistance
Application Fields
  • Elevator Systems: Primary hoisting rope ensuring smooth and safe elevator operation
  • Port & Construction Lifting: General lifting equipment for cargo handling at ports and construction sites
  • Mechanical Transmission: Power transmission and traction applications in winches and lifting machinery
  • Industrial Cranes: Gantry cranes and tower cranes for lifting and towing operations
Technical Specifications

The 8×19S+8×7+PP 1570 steel wire rope is designed for heavy-duty applications where reliability, durability, and safety are paramount. Its construction ensures optimal performance in demanding industrial environments.
