8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
Specifications
Material :
steel
Nominal Diameter :
11 mm
Construction :
8×19S+8×7+PP
Application Fields :
Elevator Industry、Lifting and Hoisting Operations、Mechanical Transmission
Number Of Wires Per Strand :
19
Product Type :
Wire Rope
Tensile Strength :
1570N/mm²
Brand Name :
Huayi
Model Number :
8×19S+8×7+PP
Place of Origin :
China
MOQ :
2000m
Payment Terms :
T/T,L/C
Supply Ability :
10000+M+
Surface Treatment :
ungalvanized
Implementation standard :
ISO 4344/ EN 12385-4
Number Of Outer Wires :
8 strands
Description
8x19S+8x7+PP - 11 Elevator Steel Rope
8×19S+8×7+PP Construction Elevator Steel Rope with 1570N/mm² Tensile Strength and 11 mm Nominal Diameter
Product Overview

The 8*19S+8*7+PP 1570 elevator steel rope is engineered for demanding lifting applications with its specialized construction and high-performance characteristics.

Structural Composition

Strand Configuration: "8*19S" indicates 8 strands with 19 wires each in Seale construction, featuring thicker outer wires for enhanced abrasion resistance. "8*7" represents an additional 8 strands with 7 wires each.

Core Material: "PP" denotes polypropylene fiber core, providing flexibility, internal lubrication storage, and anti-extrusion capabilities while maintaining chemical stability.

Performance Characteristics
  • High Strength & Abrasion Resistance: The 8*19S structure delivers exceptional strength with thick outer wires that withstand frequent friction against pulleys and components
  • Superior Flexibility: Combined 8*7 strands and fiber core maintain strength while allowing flexible bending and winding operations
  • Shock Absorption: Fiber core acts as internal buffer, reducing vibrations from impact loads and external forces
  • Continuous Lubrication & Rust Prevention: Fiber core stores lubricating oil, providing ongoing internal lubrication while preventing corrosion
Application Fields
  • Elevator Systems: Primary hoisting wire rope ensuring smooth and safe elevator operation
  • Lifting & Hoisting Operations: Port gantry cranes, construction tower cranes, and general lifting equipment
  • Mechanical Transmission: Power transmission and traction applications including winches and industrial elevators

Note: The 8*19S+8*7+PP 1570 steel wire rope is specifically designed for heavy-duty lifting equipment where strength, flexibility, and durability are critical requirements.
