Heavy-duty Welded Bent Metal Low-carbon Structure Transportation Project Steel Bridge
Our steel structure bridge is manufactured with high-strength heavy steel materials and advanced welding technology. Featuring high structural rigidity, strong bearing capacity, seismic resistance and wind resistance, it adapts to complex terrain and harsh natural environments. Professional anti-corrosion, rust-proof and weather-resistant treatment greatly extends the service life. With fast on-site installation, low comprehensive maintenance cost and flexible design, our steel bridges are widely used for highway crossings, river spans, municipal engineering and industrial transit. Customized span, load standard and overall solution are available to meet diverse engineering project requirements.
Technical Specifications
Span Range50-160 M
Altitude Band15-50 M
Anti-corrosion TreatmentGalvanizing, spraying zinc, and spraying anti-corrosion paint
Fire-protection RatingHigher than or equal to Level 2
Load TypeEnclosure materials, equipment, cranes, local natural conditions
Material IntensityS355/Q235/Q355
Tolerance±1
StandardChinese Standard/European Standard
Process ModeBending, welding, cutting, assembling, shot blasting and painting
Drawing DesignSAP2000/AutoCAD/PKPM/3D3S/TEKLA
CertificateCE
Life Length50 years
Packaging and Delivery
PortQingdao, TianJin, and HeBei
Delivery Cycle15-60 Days
Marketing UnitSquare meter
Supply Capacity10,000 tons/month
Heavy Duty Welded Bent Metal Low Carbon Structure Transportation Project Steel Bridge
Key Features
50-Year Lifespan & Long-Term Durability
High-quality structural steel (Q355q, Q420q, EN S355/S420 series) with excellent toughness and anti-fatigue performance. Professional anti-corrosion treatment (hot-dip galvanizing + epoxy zinc-rich primer + fluorocarbon topcoat) per ISO 12944 standards, ensuring 50-year service life.
121+ Mph Wind Resistance
Optimized modular truss structure with triangular framework design effectively distributes wind load. Wind resistance reaches 121+ Mph (195+ km/h), meeting requirements for hurricane-prone areas with 1.2x safety factor.
Modern Design & Modular Prefabrication
Modern minimalist design with sleek appearance. Modular prefabrication enables factory standardized production (error ≤±1mm) and reduces construction period by 40%-60% compared to traditional methods.
High Efficiency & Cost-Saving
Modular design allows flexible combination and expansion, reducing material waste and transportation costs. Lightweight structure minimizes foundation investment and saves labor costs.
Core Technology
  • Modular Truss Structure Technology: Triangular truss framework evenly distributes tensile and compressive forces, suitable for spans up to 91 meters with standardized interfaces for seamless assembly.
  • Precision Prefabrication & Welding Technology: Advanced CNC equipment with welding compliant to EN ISO 15614 and AWS D1.5 standards. 100% welding qualification rate with component precision meeting EN 10210/EN 10219 standards.
  • Anti-Corrosion & Durability Enhancement: Three-layer anti-corrosion system (hot-dip galvanizing + epoxy zinc-rich primer + fluorocarbon topcoat) with ≥80μm galvanizing layer and Z-direction performance steel.
  • Wind Resistance Optimization: Streamline truss section and aerodynamic diversion device reduce wind resistance and vortex-induced vibration, ensuring safe operation under extreme conditions.
International Standards & Key Parameters
Parameter CategoryKey SpecificationsInternational Standards
CertificationCE Certification (EXC3 Execution Class), ISO 9001, AWS D1.5EU CPR (EU 305/2011), EN 1090-1/2, ISO 9001, AWS D1.5
Lifespan50-Year Design LifespanISO 12944 (Corrosion Protection), EN 1090
Wind Resistance121+ Mph (195+ km/h), Flutter Critical Wind Speed ≥1.2*Design Wind SpeedWind Load Calculation Standards (GB/T 50009, AASHTO LRFD)
Steel MaterialQ355q, Q420q, EN S355/S420 Series, Z15/Z25/Z35 Z-direction PerformanceGB/T 714, EN 10025-2/-3/-4, ASTM A709
Modular SpecificationsSpan: 10-91m; Module Weight: 500-5000kg/unit; Section Thickness: 8-30mmEN 10210/EN 10219, ASTM A578
Welding StandardFull Penetration Welding, Welding Qualification Rate 100%EN ISO 15614, AWS D1.5, EN ISO 9606
Anti-CorrosionThree-Layer Anti-Corrosion System, Galvanizing Layer ≥80μmISO 12944, ISO 2063, ISO 1461
Application Scenarios
Our prefabricated modular steel truss bridges are widely used in various infrastructure projects, including highway and railway crossings, urban overpasses, cross-river and cross-valley bridges, industrial zone passages, emergency rescue bridges, and remote area traffic links. They are especially suitable for areas with strong wind, high humidity, and complex construction environments.
Heavy Duty Welded Bent Metal Low Carbon Structure Transportation Project Steel Bridge
Manufacturing Process
  1. Processing follows international standards (AISC 360, Eurocode 3, EN 1090) ensuring structural stability
  2. Strict raw material inspection including material certificate verification, size measurement and appearance inspection
  3. Lofting, marking and cutting performed by numerical control equipment for precise dimensions
  4. Straightening and correction (thermal or mechanical) to ensure component flatness
  5. Drilling and punching processes to meet assembly requirements
  6. Professional welding (submerged arc welding, gas shielded welding) with UT/MT non-destructive testing
  7. Secondary straightening and grinding to correct deformation and remove burrs
  8. Shot blasting to Sa2.5 derusting grade for enhanced coating adhesion
  9. Clear component marking, proper packaging and factory delivery
