Steel wall formwork is a special system for concrete pouring with modular design, which is specially developed for the construction of vertical structures such as shear walls and retaining walls of modern buildings. The product is made of 6mm high-strength Q355B steel plate as the main body, combined with a special steel skeleton, and the surface is treated with hot-dip galvanization and epoxy spraying to ensure excellent performance and durability in harsh construction environments.

Core parameters:

Standard size: 1200×2400mm/1500×3000mm (can be customized)

Load capacity: side pressure ≥ 85kN/m²

Leveling accuracy: the board surface error ≤ 1.8mm/2m

Turnaround life: standardized use can reach more than 550 times

Core Benefits:

Efficient construction: The patented quick installation system realizes 3-second locking at a single point, and the installation area exceeds 200 square meters in a single day

Precise molding: laser cutting frame and CNC positioning holes, wall verticality error ≤ 3mm/floor height

Safe and reliable: The overall stiffness is increased by 40%, completely eliminating the risk of mold expansion

Economical and environmentally friendly: the single use cost is only 20% of that of wooden formwork, and the material recovery rate is 98%

Technical features:

Intelligent adjustment system: supports 2.5-4.2m height stepless adjustment

Multiple sealing design: EPDM rubber strip maze structure to achieve zero slurry leakage

Digital management interface: Each module has a built-in RFID chip to support the whole process traceability

Strong compatibility: Perfect docking with climbing forms, sliding forms, and various support systems

Applications:

The core of a super-high-rise building

Underground comprehensive pipe gallery

Water conservancy and hydropower projects

Prefabricated component production line
