Specifications
Brand Name :
YDX
Model Number :
YDX-5SE
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
50-10000 square meters
Price :
$35.00-$63.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Construction :
Steel Frame
Working Scope :
Design,Fabrication, Installation
Product Sustainability :
Eco-Friendly
Environment Protection :
Environmental Friendly Material
Type :
Frame Building
Door :
Aluminum or steel wood door
Description
Project Description
Heavy Industrial Steel Buildings / Steel Frame Structure Building Fabrication for salt & chemical industrial projects. We provide complete 3D modeling for steel frame structures, fabricate approximately 600 tons of steel components, and coordinate installation with the General Contractor.
Key Features

Comprehensive 3D Tekla modeling services

Specialized thick paint application with dedicated indoor painting facilities

Product Specifications

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc

Heavy Industrial Steel Frame Building with H Section Design

Steel Designing & Detailing
Our dedicated engineering department provides complete steel structure design services, including optimization and deepening design. We ensure structural reliability and economy while considering material performance and architectural aesthetics.

Heavy Industrial Steel Frame Building with H Section Design

Packing & Loading
All structural components, panels, bolts, and accessories are packed to withstand ocean transportation and loaded into 40'HQ containers.
Heavy Industrial Steel Frame Building with H Section Design

Our Advantages

1. Professional Design Team We provide customized design services based on your requirements or calculate steel quantities from your existing drawings.
2. Skilled Fabrication Our advanced equipment and trained workforce follow project-specific production schedules with pre-fabrication training.
3. One-Stop Service We offer complete project solutions with extensive experience in customized steel structure projects.
4. Quality Control Dedicated QC team ensures products meet all specifications and requirements.
5. After-Sales Service Comprehensive support including maintenance services for insulation and steel components.

The following question we need to know before making the price. Just feel free to fill what you know.

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
