Specifications
Brand Name :
YDX
Model Number :
YDX-4FS
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
50-10000 square meters
Price :
$35.00-$63.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Insulation :
EPS, Glass Wool,rock Woll ,PU
Strength :
Strong
Cladding :
PU/Rock Wool/Fiberglass/EP
Roof :
Glass Wool, EPS, PU
Product Material :
Steel
Apply :
Easy to Apply
Roofing :
Sandwich Panel. Single Steel Sheet
Column And Beam :
Welded H-section
Structure :
Frame
Construction :
Steel Frame
Aesthetics :
Modern
Column :
Squre Tube
Description

Prefab Steel Warehouse with Fast Installation Q235B Q355B Material

Product Specifications

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc
Steel structure building
1. Primary Framing Box beam column, cross steel column, H-shaped steel column, steel beam
2. Secondary Framing Galvanized Z and C sections purlin
3. Roof and Wall panels Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU).
4. Steel Decking Floor Galvanized steel decking board
5.Structural subsystem Divider, gutter, awning, partition wall
6.Mezzanines, Platforms Painted or galvanized H beam
7.Other Building Accessories Sliding doors, roll up doors, aluminium windows, louvers, etc.
Service Life 50-70years support steel angle, steel pipe, steel round
Place of Origin Qingdao,Shandong,China Application workshop, warehouse, poultry house,garage etc
Grade Q235B, Q355B or as per customer's need Bolt Grade M20, M16, M14 etc
Connection intensive bolt, ordinary bolt Window PVC steel or aluminum alloy
Downspout PVC pipe or as per customer's request Door sliding or rolling door
Purlin C/Z shape profile Panel EPS/PU/fiber glass/rock wool
Main Frame Welded or hot rolled H-shaped steel, columns, beams, box beams and columns
Drawings & Quotation:
(1) Customized design is welcomed.
(2) In order to promise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.We will quote for you promptly.

Key Advantages

  • Fast construction speed: Factory prefabrication enables simple on-site installation, significantly reducing construction time
  • Construction flexibility: Adaptable to various complex environments and conditions
  • High engineering quality: Factory manufacturing ensures precise fabrication and quality control
  • Superior seismic performance: High strength and ductility of steel provides excellent earthquake resistance
  • Eco-friendly construction: Zero-waste production reduces construction waste and environmental impact

Prefab Steel Warehouse with Q235B Q355B Material Fast Installation

Service Advantages
  • Professional design: Customized drawings and steel usage calculations
  • Exquisite craftsmanship: Skilled production with advanced equipment
  • One-stop service: Comprehensive solutions from design to installation
  • Quality control: Strict adherence to international standards
  • After-sales service: Quick response and maintenance support

Prefab Steel Warehouse with Q235B Q355B Material Fast Installation

Prefab Steel Warehouse with Q235B Q355B Material Fast Installation

Quality Control
  • Raw material quality control: Thickness tolerance <0.25mm, yield and tension strength testing, third party inspection
  • Fabrication quality control: 100% dimension testing, 20% ultrasonic and magnetic powder welding tests
  • Surface treatment: Shot blasting grade SA 2.5, paint primer within 5 hours, DFT >75UM
  • Pre-assembly testing: Verification of all connection details
Packing and Delivery
  • Standard sea freight packaging: Reinforced packaging for all components
  • 40' HQ container loading: Optimized space utilization
  • Professional loading team: Skilled workers using proper equipment

Prefab Steel Warehouse with Q235B Q355B Material Fast Installation

Frequently Asked Questions
Q: Are you a manufacturer or trading company?
A: We are a manufacturer with our own factory. Customers are welcome to visit our facilities.
Q: How competitive are your prices?
A: We offer the best price for equivalent quality and the best quality for equivalent prices.
Q: Can you provide installation support?
A: We provide detailed installation drawings and can send engineers or a full installation team upon request.
Q: Do you accept third-party inspections?
A: Yes, we welcome inspectors at any stage of production.
Q: Do you offer design services?
A: Yes, we provide complete design solutions using AutoCAD, PKPM, Tekla Structures and other professional software.
Q: What is your typical delivery time?
A: Approximately 40 days after deposit receipt for standard orders.
Q: How can I get a quotation?
A: Contact us via email, phone, or WhatsApp - we respond within 8 hours.
