Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Specifications
Brand Name :
YDX
Model Number :
YDX-DF
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
10-10000 square meters
Price :
$30.00-$65.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Construction Type :
Frame
Visit :
Acceptable
Design Options :
Flexible
Assembly Time :
Fast
Material :
Steel
Cladding :
PU/Rock Wool/Fiberglass/EPS
Product Insulation :
Thermal Insulation
Toughness :
Good Toughness
Surface Treatment :
Painted Or Galvanized
Usage :
Commercial/Industrial/Residential
Steel Grade :
Q235B Q345b Low Carbon Steel
Product Design :
Customizable
Roofing :
Sandwich Panel. Single Steel Sheet
Color :
Client's Request
Structure Type :
Frame
Frame Type :
Steel Frame
Earthquake Resistance :
Strong
Windows :
Aluminum
Seismic Design :
High Seismic Zone
Installation Time :
Short
Aesthetics :
Modern
Cost :
Moderate
Product Resistance :
Corrosion Resistant
Finish :
Galvanized/Painted/Cladding
Roof :
Glass Wool, EPS, PU
Product Fire Resistance :
Fireproof
Door :
Sliding Door or Rolling Door
Description

Prefab Steel Structure Warehouse with H-Section Beams 50-Year Lifespan

Product Description
Our industrial steel structure warehouse combines strength, functionality, and efficiency. The robust design features a sleek industrial exterior with steel panel walls and a durable steel roof. The interior offers vast open space with sturdy columns and beams for maximum support and stability.
The structure is designed for optimal functionality with wide aisles and clear spans for easy equipment movement. Natural lighting through large windows and skylights reduces energy costs, while high ceilings maximize vertical storage capacity.
Key advantages include:
  • 50+ year service life with minimal maintenance
  • Resistance to fire, pests, and extreme weather conditions
  • Faster construction time compared to traditional methods
  • Cost-effective long-term solution
  • Customizable for various industrial applications
Technical Specifications
Component Specification
Main Steel Frame (Column/Beam) Q235, Q355 Welded H Section Steel
Secondary Frame (Purlin/Knee Brace) Q235 C and Z purlin, Angle Steel
Roof Panel EPS/Glass Fiber/Rock Wool/Pu Sandwich Panel or Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Wind Resistance Grade 12
Earthquake-resistance Grade 8
Temperature Range -50°C to +50°C
Finishing Options Wide range of colors and textures available
Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc

Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan

Why Choose Us
  • Professional design team for customized solutions
  • Skilled fabrication with advanced equipment
  • Complete one-stop service for steel structure projects
  • Strict quality control at every production stage
  • Comprehensive after-sales support and maintenance

Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan

Packing and Loading
All structural components, panels, bolts and accessories are packed with standard ocean transportation packaging and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to prevent damage during loading.
Prefab Steel Warehouse with H-Section Beams 50-Year Lifespan
Request a Quote
Please provide the following information for an accurate quotation:
1. Location (where will it be built?) _____country, area
2. Size: length*width*height _____mm*_____mm*_____mm
3. Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4. Snow load (max. snow height) _____kn/m2, _____mm
5. Anti-earthquake requirement _____level
6. Brick wall needed If yes, 1.2m high or 1.5m high
7. Thermal insulation EPS, fiberglass wool, rockwool, PU sandwich panels or metal sheets
8. Door quantity & size _____units, _____(width)mm*_____(height)mm
9. Window quantity & size _____units, _____(width)mm*_____(height)mm
10. Crane requirement If yes, _____units, max. lifting weight____tons; max. lifting height _____m
