Industrial Liquid Mixing Tank / Agitator Mixing Tank For Milk Production
Industrial Liquid Mixing Tank / Agitator Mixing Tank For Milk Production
Industrial Liquid Mixing Tank / Agitator Mixing Tank For Milk Production
Industrial Liquid Mixing Tank / Agitator Mixing Tank For Milk Production
Specifications
Model Number :
KQ ,OEM
Certification :
SGS ,ISO
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 Set Per Month
Delivery Time :
20 Days after get your advance payment
Packaging Details :
Standard Wooden Box
Name :
heated stainless steel tank
Material :
Stainless Steel 304 / 316 / 316L
Capacity :
100L to 30000L
Heating :
Steam Heating / Electric Heating
Motor :
ABB / SEW / SIEMENS
Surface Treatment :
Inside Mirror and Outside Polished
Accessory :
Level Meter , Air Vent , CIP Ball ,Thermometer , Pressure Guage
Cleaning :
CIP Cleaning Ball
Description

304 316 Stainless Steel Liquid Jacketed Heating Mixing Tank For Milk Production

1. Introduction of Liquid Mixing Tank :

Tank Part:


Material :Sanitary Stainless Steel 304


* Type: with Jacket and insulation
* Internal shell thickness: 3 mm (SS304)
* Jacket thickness: 3 mm (SS304)
*PU Insulation wall:50mm
*Outer shell thickness: 1.5mm (SS304)
* Appearance: Tank will be like the right tank picture
Tank picture is for ref


* Accessories included:


(1) Manhole
(2) Auto CIP Cleaning Ball
(3) Motor & Gear Box
(4) Mixing System
(5) Heating Transfer Oil Inlet /Outlet
(6) Material Inlet /Outlet
(7) Electricity Control Box
(8) Electric Heating Bar
(9) Thermometer
(10) Legs
(11) Name Plate

2. Technical Parameter :

Tank Capacity(L) 1000L
Application Milk Industry
Material Food Grade Stainless Steel 304
Surface Treatment Inside Mirror and Outside Polished
Motor Brand Siemens
Electric Control Panel Yes
Voltage /Hz /Phase Make to your order .
REV 36r/min
Electric motor of the agitator 1.1KW, Voltage ,make to your order .
The Max Working Temperature of Heating Transfer Oil 220 ℃
Max Working Temperature 180 ℃
Electric heating tube power 48KW,
Heating Area(M2) 4.5
Content Input / Output(DN MM) 38
Dimension (L*W*H)MM 1400*1400*1750
Gross Weight (KGS) 350

Industrial Liquid Mixing Tank / Agitator Mixing Tank For Milk Production
