Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
Specifications
Model Number :
KQ 1000L , KQ 2000L , KQ3000L
Certification :
CE ,ISO ,FDA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
600 Set / Month
Delivery Time :
25 days after get your advance payment .
Packaging Details :
Standard Export Wooden Cases
Name :
liquid storage tanks
Usage :
Beverage, Food Industry ,Cosmestic , Chemistry
Function :
Steam / Electric Heating , Mixing and Fermentation
Treatment :
Inside Mirror and Outside Polished
Motor Brand :
Siemens , ABB , SEW
Speed of Mixer :
18RPM ,36RPM ,48RPM ,72RPM ,2900RPM
Thickness of wall :
According to your requirement
Warranty :
2 Years after reach your side
Description

304 316 Beverage Stainless Steel Liquid Mixing Tank Heating Tank Storage Tank

1. Introduction of mixing tank:

Product Description
Mixing tank
(pressure vessel available)
Material: 304 or 316L
Volumn: 500L ~20000L
Agitator: Chinese or European
Single or Jacket (steam or chilling)
Isolation: PU foam or rock wool
Configure:
Manhole
Level garuge
Ladder
Adjustable legs

2. Technical Details :

Volume(L) Dimension Total Height(mm) Inlet &
Outlet(mm)		 Motor
Power(kw)		 Motor
Speed(rpm)
500 840 x 1000 2750 38 0.55 Common rotation speed is 36, 43, 60rpm. Stepless speed reducer or dual-speed reducer is also available
600 920 x 1000 2850 38 0.55
700 990 x 1000 2850 38 0.55
800 950 x 1220 3000 38 0.55
900 1010 x 1220 3000 38 0.55
1000 1060 x 1220 3150 51 0.75
1500 1160 x 1500 3350 51 0.75
2000 1340 x 1500 3410 51 1.1
3000 1410 x 2000 4000 51 1.5
4000 1620 x 2000 4250 51 1.5
5000 1810 x 2000 4300 51 2.2
6000 1980 x 2000 4550 51 2.2
7000 1930 x 2440 5000 51 2.2
8000 2060 x 2440 5000 51 3
9000 2180 x 2440 5050 51 3
10000 2300 x 2440 5050 51 3
12000 2270 x 3000 5600 51 4
15000 2530 x 3000 5700 51 4
20000 2640 x 3660 6400 51 5.5

Stainless Steel Liquid Mixing Tank For Beverage / Food Industry FDA Approved
