Specifications
MOQ :
1 Ton
Price :
US $790-1,158 / Ton
Technique :
Hot Rolled
Width :
10-2600mm
Thickness :
5mm-80mm
Length :
6m, 8m, 10m or custom
Hardness HRC :
5.0 - 80.0mm
Yield Strength :
1250 MPa
Tensile Strength :
1450 MPa
Elongation :
8%
Impact Strength :
-30C
Hardness Range :
450-540
Carbon Content :
0.30
Silicon Content :
0.7
Manganese Content :
1.70
Chromium Content :
1.00
Boron Content :
0.005
Description
AR500 Abrasion Resistant Steel Plate with Hardened Surface NM500
AR500 abrasion resistant steel plate features a hardened surface and is specifically engineered for extended service life in demanding industrial environments. These premium steel plates deliver exceptional performance in applications requiring high impact and abrasion resistance.
Product Specifications
Description Abrasion Resistant Steel Plate
HRC 5.0 - 80.0mm
Related Materials NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600
Thickness 5mm - 80mm
Width 1500mm, 2000mm, 2200mm
Length 6m, 8m, 10m or custom cutting as requested
Price Terms EX-Work, FOB, CFR, CIF
Payment Terms T/T, L/C, Western Union
Chemical Composition
Grade C Si Mn P S Cr Ni Mo B
AR500 0.30 0.7 1.70 0.025 0.015 1.00 0.70 0.50 0.005
AR450 0.26 0.7 1.70 0.025 0.015 1.00 0.70 0.50 0.005
AR400 0.25 0.7 1.70 0.025 0.015 1.50 0.70 0.50 0.005
AR300 0.18 0.7 1.70 0.025 0.015 1.50 0.40 0.50 0.005
Mechanical Properties
Grade Yield Strength (MPa) Tensile Strength (MPa) Elongation A Impact Strength Charpy V 20J Hardness Range
AR500 1250 1450 8 -30°C 450-540
AR450 1200 1450 8 -40°C 420-500
AR400 1000 1250 10 -40°C 360-480
AR300 900 1000 11 -40°C -
Applications
  • AR400: Premium abrasion resistant steel plates with heat treatment and through-hardening, featuring improved forming and welding capabilities
  • AR450: Abrasion resistant plate used in applications requiring slightly greater strength than AR400
  • AR500: Suitable for mining, forestry and construction applications
  • AR600: Utilized in high-wear areas including aggregate removal, mining, and manufacturing of buckets and wear bodies
Abrasion resistant steel plates are ideal for mining, quarrying, conveyors, material handling, construction, and earthmoving applications. These products extend service life of critical components while reducing unit weight in demanding operational conditions.
Shipping & Packaging
Delivery: Within 7-30 days after order confirmation
Packaging: Standard seaworthy export packing with bundled steel straps, customizable as required
Shipping Time: 5-7 work days after delivery
Shipping Method: By Sea
Shipping Port: Shanghai
Container specifications: 20ft GP (5.8m × 2.13m × 2.18m, ~24-26 CBM) and 40ft GP (11.8m × 2.13m × 2.72m, ~68 CBM). All products include surface protection meeting export standards.
