Specifications
MOQ :
1 Ton
Price :
US $730-1,450 / Ton
Thickness :
6MM to 300MM
Width :
1500mm to 4050mm
Length :
3000mm to 15000mm
Technique :
Hot Rolled
Carbon Content :
0.27-0.31%
Silicon Content :
0.13-0.45%
Manganese Content :
0.79-1.30%
Phosphorus Content :
0.035%
Sulfur Content :
0.035%
Yield Strength :
260 Mpa
Tensile Strength :
485-620 Mpa
Elongation :
17-21%
Carbon Equivalent :
Ceq = C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15%
Production Capacity :
500000kgs
Supplementary Technology :
HIC Test, NACE MR0175, Z15, Z25, Z35, S1-S9, S11, S12, S14, S17
Description
Carbon Steel Plate 20mm Thick ASTM A572, Gr 50, S355 (Grade 50ksi)
ASME SA516 GR 70 Plate Boiler and Pressure Vessel Hot Rolled Astm A516 Gr 70 Mechanical Specifications
ASME SA516 Steel Plate
SA516Gr70 | ASME SA516 Grade 70 | SA516 Gr.70 STEEL PLATE
ASME SA516 standard specification for pressure vessel plates, carbon steel for moderate and lower-temperature service.
ASME SA516 plates 40mm and under in thickness is normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both. ASME SA516 grade plates over 40mm in thickness shall be normalized.
Supplementary Technology
  • HIC Test
  • NACE MR0175
  • Z15 | Z25 | Z35
  • S1 | S2 | S3 | S4.1 | S5 | S6 | S7 | S8 | S9 | S11 | S12 | S14 | S17
Available Dimensions
  • Thickness: 6MM to 300MM
  • Width: 1500mm to 4050mm
  • Length: 3000mm to 15000mm
Gangsteel is specialized in supplying ASME SA516 steel plate in SA516 grade 70.
SA516 Grade 70 Chemical Composition
Grade SA516 grade 70 C Si Mn P S
Thick <12.5mm 0.27 0.13-0.45 0.79-1.30 0.035 0.035
Thick 12.5-50mm 0.28 0.13-0.45 0.79-1.30 0.035 0.035
Thick 50-100mm 0.30 0.13-0.45 0.79-1.30 0.035 0.035
Thick 100-200mm 0.31 0.13-0.45 0.79-1.30 0.035 0.035
Thick >200mm 0.31 0.13-0.45 0.79-1.30 0.035 0.035
Carbon Equivalent: Ceq = C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15%
SA516 Grade 70 Mechanical Property
Grade Thickness Yield Min Mpa Tensile Mpa Elongation Min %
SA516 grade 70 6-50 mm 260 485-620 21%
SA516 grade 70 50-200 mm 260 485-620 17%
Related Steel Plate Categories
Shipbuilding steel plate Alloy steel plates High strength plate Carbon steel plate Stainless steel plate
Equivalent Steel Grade of SA516 Grade 70
Europe Belgium Germany France Italy Sweden India Japan
E St E315 Fe 460-2-KG SS29,12,01
If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.
