65Mn Hot Rolled Spring Steel Plate for Boiler Plate Applications with High Strength
65Mn Hot Rolled Spring Steel Plate for Boiler Plate Applications with High Strength
Specifications
MOQ :
1 Ton
Price :
US $780-1,450 / Ton
Model NO. :
65mn
Technique :
Hot Rolled
Width :
100-3000mm
Production Capacity :
500000kgs
Thickness :
0.3mm-2.5mm
Thickness Tolerance :
+/-0.015mm
Width Range :
10mm - 900mm
Coil Weight :
0.1~3.5MT
Min Order :
20MT
Tensile Strength :
825~925 MPA
Yield Strength :
520~690 MPA
Elongation :
14~21.5
Reduction Area :
More than 10
Hardness :
240~270HB
Chemical Composition :
C: 0.62~0.70, Si: 0.17~0.37, Mn: 0.90~1.20, P: ≤0.035, S: ≤0.035, Cr: ≤0.25, Ni: ≤0.25, Cu: ≤0.25
Description
65Mn Spring Steel Plate - Hot Rolled AISI 1066 / ASTM 1566
High-quality 65Mn spring steel strip featuring excellent mechanical properties and versatile applications across multiple industries.
Available Steel Strip Types
  • Bright Steel Strip
  • Black Annealed Steel Strip
  • Cold Hardened Steel Strip
Technical Specifications
Quality/Industry Standards: Temper Rolled (Full Hard, Half Hard, Quarter Hard), Drawing, Deep Drawing, Extra Deep Drawing, Mediums High Carbon or equivalent materials.
Available Specifications: BS/DIN/ASTM/JIS and equivalent standards
Thickness: 0.3mm - 2.5mm (Tolerance: ±0.015mm)
Width: 10mm - 900mm
I.D.: 200mm / 500mm (slit edge: 508mm)
Coil Weight: 0.1 - 3.5 MT
Packaging Details
Mill Edge: 4 steel strapping and 2 wire rod through coil eye, 1 steel strapping on coil circumference; 3-4 strips bundled into larger coil, max 3MT per package.
Slit Edge: 6 steel strapping through coil eye, 1 steel strapping on coil circumference; 3-4 strips bundled with edge protection; max 3MT per package.
Minimum Order: 20MT per size
Spring Steel Strip Specifications
Steel Grade: 65Mn, 50CrV, 60Si2MnA, 62Si2MnA
Custom Specifications: Thickness: 0.2-4.0mm, Width: 3-400mm (as per customer request)
Delivery State: Surface Polishing + Blueing
Applications
  • Appliances parts
  • Automotive and motorcycle components
  • Watches and instrument parts
  • Optical communication components
  • Medical equipment parts
  • Motor shaft parts
  • Laser printer components
  • Office supplies parts
  • Sanitary products
Chemical Composition
Grade C Si Mn P S Cr Ni Cu
65Mn 0.62-0.70 0.17-0.37 0.90-1.20 ≤0.035 ≤0.035 ≤0.25 ≤0.25 ≤0.25
50CrV 0.46-0.54 0.17-0.37 0.50-0.80 ≤0.030 ≤0.030 0.80-1.10 ≤0.35 ≤0.25
60Si2MnA 0.52-0.60 1.5-2.0 1.00-1.30 ≤0.035 ≤0.035 ≤0.35 ≤0.35 ≤0.25
Mechanical Properties
Grade Tensile Strength (MPa) Yield Strength (MPa) Elongation Reduction of Area Hardness
65Mn 825-925 520-690 14-21.5 >10 Hot-rolled 240-270HB
50CrV ≥1274(130) ≥1274(130) ≥10 ≥40 Hot-rolled ≤321HB; Cold drawn+Heat treatment ≤321HB
60Si2MnA ≥1372(140) ≥1225(125) ≥5 ≥30 Hot-rolled ≤321HB; Cold drawn+Heat treatment ≤321HB
Our company is committed to developing with customers through first-class hardware, software, and expert teams. We manufacture products to customer satisfaction while maximizing value and striving for a prosperous future together.
Note: Chemical composition and mechanical performance index provided upon request.
