Specifications
MOQ :
1 Ton
Price :
US $750-1,450 / Ton
Width :
100-3000mm
Technique :
Hot Rolled
Carbon Content :
0.20%
Silicon Content :
0.40%
Manganese Content :
0.80-1.40%
Phosphorus Content :
0.025%
Sulfur Content :
0.015%
Aluminum Content :
0.020%
Nitrogen Content :
0.012%
Yield Strength :
265-215 MPa
Tensile Strength :
410-530 MPa
Elongation :
22%
Impact Energy :
27-40 J
Thickness Range :
≤16mm to ≤250mm
Chromium Content :
0.30%
Description
P265GH Steel Plate - Heat Resistant Pressure Vessel Steel
Grade P265GH is a heat resistant pressure vessel steel defined in the EN 10028 system. This non-alloy steel is specifically designed for high temperature applications, making it ideal for use in the oil and gas sector, chemical processing industries, and petrochemical sectors.
P265GH Chemical Composition Maximum (%)
Grade C Si Mn P S Al(min) N
P265GH 0.20 0.40 0.80-1.40 0.025 0.015 0.020 0.012
Cr Cu Mo Nb Ni Ti V
0.30 0.30 0.08 0.020 0.30 0.03 0.02
P265GH Mechanical Properties
Grade Thickness (mm) Yield Min (MPa) Tensile (MPa) Elongation Min (%) Impact Energy (KV J) min
P265GH ≤ 16 265 410-530 22 27
16 > to ≤ 40 255 410-530 22 27
40 > to ≤ 60 245 410-530 22 27
60 > to ≤ 100 215 410-530 22 27
100 > to ≤ 150 200 400-530 22 27
150 > to ≤ 250 185 390-530 22 40
Related Steel Plate Grades
Ordinary Carbon Structural Steel Plate: Q235A, Q275A, Q295A, SS400, AS3678-250, A36, SM400A, St37-2, SA283GrA, S235JR, S235J0, S235J2, S275JR, S275J0, S275J2, S275N, S275NL, etc.
Low Alloy High Strength Steel Plate: Q345A, Q355B, Q390A, Q420A, S420N, LS420M, S460M, S420ML/S460ML, AS3678-300, AS3678-350, S460N, S460NL, SM490B, SM490YB, A572Gr50, A572Gr65, St52-3, S355JR, A709Gr50, A633C/D, A633E, SM520, SM570, S315, StE355, StE460, S355JO, S355J2, S355J2W, S355K2, S355N, S355NL.
Offshore Structural Steel Plate: S355G2+N, S355G3+N, S355G5+M, S355G6+M, S355G7+M, S355G7+N, S355G8+M, S355G8+N, S355G9+M, S355G9+N, S355G10+M, S355G10+N.
Steel Plates for Boilers and Pressure Vessels: SA387Gr11, SA387Gr22, 15MnNiR, 12Cr1MoVR, A515Gr60, (S)A515Gr65, (S)A515G70, (S)A516Gr60, (S)A516Gr65, (S)A516Gr70, (S)A516Gr415, (S)A516Gr485, SPV355, SPV450, 19Mn6, 15Mo3, 16Mo3, A573Gr70, SA285GrC, SB41, SP235GH, HII/P265GH, P295GH, P275NH, P275NL1, P355GH, P355NH, P355NL1, SA662GrC, P460NH, A537CL1, A537CL2 (quenched and tempered steel), etc.
Steel Plate for Bridge: Q235QC, Q345QC, Q370QC, Q420QC, Q345QDNH, Q370QDNH, A709-50F-2, A709-50T-2.
EN 10207 P265GH Steel Plate
  • EN 10207 covers steels for simple pressure vessels, defined as any welded vessel subject to internal gauge pressure greater than 0.5 bar intended to contain air or nitrogen and not intended to be fired.
  • We supply steel certified to EN 10207 P265S as plate, cut plate, or profiles (cut shapes).
  • EN 10207 P265S is steel for pressure purposes with minimum yield strength of 265 MPa, featuring specified mechanical properties at elevated temperatures.
  • This material is delivered in the normalized condition or an equivalent condition obtained by normalized rolling.
For any other steel plate requirements, please feel free to contact us.
