Specifications
MOQ :
1 Ton
Price :
US $730-1,250 / Ton
Model NO. :
P265GH, P355GH, 16Mo3, 15Mo3, A204
Technique :
Hot Rolled
Width :
100-3000mm
Thickness :
5-300mm
Length :
3000-12000mm
Carbon Content :
0.20%
Silicon Content :
0.40%
Manganese Content :
0.80-1.40%
Phosphorus Content :
0.025%
Sulfur Content :
0.015%
Yield Strength :
265-185 Mpa
Tensile Strength :
390-530 Mpa
Elongation :
22%
Impact Energy :
27-40J
Production Capacity :
500000kgs
Description
Pressure Vessel Steel Plate P265GH, P355GH, 16Mo3, 15Mo3, A204
P265GH steel plate is a heat-resistant pressure vessel steel defined in the EN 10028 system. This non-alloy steel is specifically designed for high-temperature applications, making it ideal for use in oil and gas, chemical processing, and petrochemical industries.
P265GH Chemical Composition
Element Content (%) Element Content (%)
C0.20 maxCr0.30 max
Si0.40 maxCu0.30 max
Mn0.80-1.40Mo0.08 max
P0.025 maxNb0.020 max
S0.015 maxNi0.30 max
Al0.020 minTi0.03 max
N0.012 maxV0.02 max
P265GH Mechanical Properties
Thickness (mm) Yield Strength Min (MPa) Tensile Strength (MPa) Elongation Min (%) Impact Energy (J)
≤ 16265410-5302227-40
16 to 40255410-5302227-40
40 to 60245410-5302227-40
60 to 100215410-5302227-40
100 to 150200400-5302227-40
150 to 250185390-5302227-40
Available Steel Grades
Carbon Structural Steel
Q235A, Q275A, Q295A, SS400, AS3678-250, A36, SM400A, St37-2, SA283GrA, S235JR
Low Alloy High Strength
Q345A, Q355B, Q390A, Q420A, S420N, LS420M, S460M, S460NL, SM490B, A572Gr50
Offshore Structural
S355G2+N, S355G3+N, S355G5+M, S355G6+M, S355G7+M, S355G8+M, S355G9+M
Boilers & Pressure Vessels
SA387Gr11, SA387Gr22, 15MnNiR, 12Cr1MoVR, A515Gr60, A516Gr70, SPV355, 19Mn6
Product Specifications
Steel Category
Boilers and Pressure Vessels
Standard
EN10028-2
Dimensions
Thickness: 5-300mm
Width: 1500-3500mm
Length: 3000-12000mm
Delivery Condition
Hot Rolled, Control Rolled, or Normalized
Applications
P265GH steel plate offers excellent tensile strength, toughness, plasticity, and processing properties. It can be rolled into steel plates, shaped steel, and profile steel for various industrial applications including:
  • Workshop construction
  • Bridge building
  • Pressure vessels
  • Chemical processing equipment
  • Petrochemical facilities
  • Oil and gas industry components
Global Supplier Network: We maintain hundreds of thousands of tons of ex-stock inventory through our spot trade platform, serving customers across Europe, America, Southeast Asia, Middle East, South America, and Africa.
