Specifications
MOQ :
1 Ton
Price :
US $750-1,450 / Ton
Model NO. :
P265gh
Technique :
Hot Rolled
Width :
100-3000mm
Production Capacity :
500000kgs
Carbon Content :
0.20%
Silicon Content :
0.40%
Manganese Content :
0.80-1.40%
Phosphorus Content :
0.025%
Sulfur Content :
0.015%
Aluminum Content :
0.020%
Nitrogen Content :
0.012%
Yield Strength :
265-185 Mpa
Tensile Strength :
410-530 Mpa
Elongation :
22%
Impact Energy :
27-40 KV J
Description
P265GH Steel Plate - Heat Resistant Pressure Vessel Steel
P265GH is a non-alloy heat resistant pressure vessel steel defined in the EN 10028 system, specifically designed for high temperature applications. This material is widely utilized in demanding industrial sectors including oil and gas, chemical processing, and petrochemical industries.
Chemical Composition (Maximum %)
Grade C Si Mn P S Al(min) N
P265GH 0.20 0.40 0.80-1.40 0.025 0.015 0.020 0.012
Cr Cu Mo Nb Ni Ti V
0.30 0.30 0.08 0.020 0.30 0.03 0.02
Mechanical Properties
Grade Thickness (mm) Yield Min (MPa) Tensile (MPa) Elongation Min (%) Impact Energy (KV J) min
P265GH ≤ 16 265 410-530 22 27
16 > to ≤ 40 255 410-530 22 27
40 > to ≤ 60 245 410-530 22 27
60 > to ≤ 100 215 410-530 22 27
100 > to ≤ 150 200 400-530 22 27
150 > to ≤ 250 185 390-530 22 27
Related Steel Plate Grades
Ordinary Carbon Structural Steel Plate: Q235A, Q275A, Q295A, SS400, AS3678-250, A36, SM400A, St37-2, SA283GrA, S235JR, S235J0, S235J2, S275JR, S275J0, S275J2, S275N, S275NL
Low Alloy High Strength Steel Plate: Q345A, Q355B, Q390A, Q420A, S420N, LS420M, S460M, S420ML/S460ML, AS3678-300, AS3678-350, S460N, S460NL, SM490B, SM490YB, A572Gr50, A572Gr65, St52-3, S355JR, A709Gr50, A633C/D, A633E, SM520, SM570, S315, StE355, StE460, S355JO, S355J2, S355J2W, S355K2, S355N, S355NL
Offshore Structural Steel Plate: S355G2+N, S355G3+N, S355G5+M, S355G6+M, S355G7+M, S355G7+N, S355G8+M, S355G8+N, S355G9+M, S355G9+N, S355G10+M, S355G10+N
Steel Plates for Boilers and Pressure Vessels: SA387Gr11, SA387Gr22, 15MnNiR, 12Cr1MoVR, A515Gr60, (S)A515Gr65, (S)A515G70, (S)A516Gr60, (S)A516Gr65, (S)A516Gr70, (S)A516Gr415, (S)A516Gr485, SPV355, SPV450, 19Mn6, 15Mo3, 16Mo3, A573Gr70, SA285GrC, SB41, SP235GH, HII/P265GH, P295GH, P275NH, P275NL1, P355GH, P355NH, P355NL1, SA662GrC, P460NH, A537CL1, A537CL2
Steel Plate for Bridge Construction: Q235qc, Q345qc, Q370qc, Q420qc, Q345qDNH, Q370qDNH, A709-50F-2, A709-50T-2
