316 Stainless Steel Equal Angle 1/2 to 6 Inch Cut to Size

Shangyou Stainless Steel supplies Type 316 equal angle in imperial dimensions for distributors, fabricators, equipment manufacturers and project buyers serving chemical, food, pharmaceutical and industrial markets.

Type 316 is UNS S31600 and EN 1.4401. Its molybdenum-alloyed composition provides greater corrosion resistance than standard chromium-nickel 304 in many demanding environments.

The stated 1/2 to 6 inch range refers to nominal leg width. Thickness, inside radius and actual dimensional availability vary with each leg size and production route.

Imperial orders should state leg width × leg width × thickness × length. Mixing inch and millimetre dimensions without identifying the governing unit system can create dimensional disputes.

The order should also state whether an exact imperial size is mandatory or whether the closest commercially available metric section is acceptable.

Type 316 angle is used in chemical-processing supports, food and beverage equipment, pharmaceutical machinery, pulp and paper equipment, brackets, frames, valves and general industrial fabrication.

For extensively welded structures, 316L may be preferred. For severe seawater or high-chloride immersion, duplex grades should be evaluated.

1. Does 1/2 to 6 inch refer to thickness?No. It refers to nominal leg width.

2. Are all sizes stocked?No. Availability depends on size, thickness, grade and manufacturing route.

3. Can you supply 20 ft lengths?Yes, subject to production and shipping arrangements.

4. Can inch sizes be cut in millimetres?Yes, provided the final cutting dimensions are clearly stated.

5. Is Type 316 the same as 316L?No. They have different carbon limits and grade designations.

6. Is polished finish available?Yes, with agreed grit and acceptance criteria.

7. Can you add bolt holes?Yes, according to drawings.

8. Can you supply small quantities?Small quantities may be available from stock or combined production.

9. How is dimensional conformity checked?Legs, thickness, angle, length and straightness can be inspected.

10. What information is needed for a quote?Grade, size, thickness, length, quantity, finish, processing and destination.
