12V 24V 36V 48V Solar Charging Controller Mppt 40A Solar Charge Controller
12V 24V 36V 48V Solar Charging Controller Mppt 40A Solar Charge Controller
Specifications
Brand Name :
SZSSTH
Model Number :
MPS 40A
Certification :
CE RHOS BSI
Place of Origin :
Guangdong, China
MOQ :
1 pieces
Price :
$68-74/pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
5000 piece/month
Delivery Time :
7 Days
Packaging Details :
color box
Type :
MPPT
Work Time (h) :
24H
Rated Voltage :
12v 24v 36v 48v
Weight :
2.94kg
Warranty :
1 Year
Product name :
mppt regulator 40a
Description

Efficient, Intelligent, and Versatile: MPPT Solar Charge Controller Series

Harness Solar Power with Maximum Efficiency

Our MPPT Solar Charge Controller Series is designed to optimize energy conversion, delivering up to 98% power generation efficiency. With a wide input voltage range of 18-150VDC, it seamlessly supports 12V/24V/36V/48V battery systems, making it ideal for diverse solar applications.

Key Features

Intelligent Temperature Control: Equipped with a cooling fan to ensure optimal performance under varying conditions.

HD LCD Display: Real-time monitoring of solar panel status, charging progress, and DC load indicators.

User-Friendly Interface: Easy navigation with scroll buttons and menu options for adjustable parameters.

Comprehensive Protections: Built-in safeguards to protect your system, housed in a Class V-0 flame-retardant enclosure.

Expandable Connectivity: Supports RS485 communication, PC software monitoring, and WiFi module expansion for APP cloud monitoring.

Product Name
MPS 30A
MPS 40A
MPS 60A
MPS 80A
MPS 100A
System Rated Voltage
12/24/36/48VDC or Self-identification
Controller operating voltage range
12-64V
Lead-acid battery type
Maintenance-free(default) /Colloid /Liquid /Custom
Lithium battery type
Lithium Iron Phosphate /Ternary Lithium /Custom
Rated charging current
30A
40A
60A
80A
100A
Rated charging power
390W /12V
540W/12V
800W/12V
1040W/12V
1300W/12V
1080W/24V
1600W/24V
2080W/24V
2600W/24V
1620W/36V
2400W/36V
3120W/36V
3900W/36V
2160W/48V
3200W/48V
4160W/48V
5200W/48V
Maximum open ccircuit voltage of photovoltaic modules
150V (under the lowest temperature condition)
138V (under 25℃ condition)
Maximum power point operating voltage range
12V System
20~150VDC
24V System
36~150VDC
36V System
48~150VDC
48V System
64~150VDC
Tracking efficiency
≥99.5%
Maximum conversion efficiency
97.50%
Temperature compensation coefficient
-3mV/ ℃ /2V
Statuc loss
350mA/12V: 170mA/24V: 85mA/48V
700mA/12V: 350mA/24V: 175mA/48V
DC Load output voltage
Can be turned on in 12V/24V Moode
DC load rated output current
40A
DC load output control
Normally open ormally closed mode /Time control mode /Light control mode
Protective function
PV input reverse connection protection
Battery input reverse connection protection
Battery overcharge protection
Battery under voltage protection
Battery over tempearature protection
Machine over temperature protection
Colling Method
Wind cooling
Way of communication
RS485
LDC Backlight time
Default 60S, Backlight mode cab be set
Environmental parameters
Working environment temperature range
-20℃ ~＋50℃
Storage temperature range
-40℃ ~＋70℃
Relative humidity range
0 ~ 90%RH
Mechanical parameters
Dimensions
210*150*80mm
219*300*110mm
219*300*110mm
275*363*109mm
275*363*109mm
Recommened wiring
9AWG/6mm²
7AWG/6mm²
6AWG/6mm²
4AWG/6mm²
2AWG/6mm²
Net weight
1.45kg
2.94kg
2.94kg
4.56kg
4.56kg
