Balustrade Infill Cable Mesh Railing Black Oxide , AISI Stair Barrier Safety Nets
Balustrade Infill Cable Mesh Railing Black Oxide , AISI Stair Barrier Safety Nets
Balustrade Infill Cable Mesh Railing Black Oxide , AISI Stair Barrier Safety Nets
Balustrade Infill Cable Mesh Railing Black Oxide , AISI Stair Barrier Safety Nets
Specifications
Brand Name :
Jianping
Model Number :
JP-24100F
Certification :
CE , SGS
Place of Origin :
Hebei
MOQ :
10 Sqm
Price :
USD 5-30/m2
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
9000m2/week
Delivery Time :
5-8 Work Days
Packaging Details :
Package film for each piece,Several pieces packed in 1 carton
Product Name :
Stainless Steel Cable Netting,Wire Rope Mesh
Material :
Stainless Steel Wire, 304, 316, AISI 304/316/304L/316L
Wire Diameter :
1.2 Mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm
Size Of Hole :
25*25mm-300*300mm
Finished :
Ultrasonic Bath , Black Oxide
Mesh Angle :
60 Degree
Mesh Shape :
Rhombus , Diamond
Mesh Type :
Ferruled Or Knotted
High Light :
Stainless Steel Rope Mesh, Stainless Steel Cable Netting
Application :
Zoological Enclosures , Blustrade Infill , Facade Cladding
Description

Balustrade Infill System With Bridge Stairway AIS316 Flexible Stainless Steel Cable Netting

1. Specification of Cable Mesh Railing:

We are happy to introduce you to an exciting product: SS304 316 Cable Mesh Net/Wire Rope Fence for Tensile Project, which is woven from high quality 304,316 and 316L stainless steel wire rope, and all the raw material for producing stainless steel wire cable mesh is imported from South Korea and Japan.Our Stainless Steel Wire Mesh & Wire Cloths with the high tech machines using high grade stainless steel wire. Our Stainless Steel Wire Rope Mesh for Skywalk in Zoo or Gardens are also not affected by acids and excessive heat. It has great advantage over ordinary wire cable mesh.

Balustrade Infill System With Bridge Stairway AIS316 Flexible Stainless Steel Cable Netting Project:

The stainless steel rope mesh is manufactured using a unique hand-woven interlocking technique from standard 7” x 7” and 7" x 19" ,stainless steel cable to create diamond openings from 1” through 4”.

1. Material : Stainless steel 304,304L,316,306L etc.
2. Ferrules Material : Tinned-copper,Nickel-plated copper, Stainless steel etc.
3. Cable construction and Diameter : 7x7 (Dia.: 1.2 - 2.5mm), 7x19 (Dia.: 3.0 - 4.0mm)

Balustrade Infill System With BridgStairway AIS316 Flexible Stainless Steel Cable Netting

Hole Size

(Opening)

1.2MM(3/64)

(7 x 7 )

1.6MM(1/16)

(7 x 7 )

2.0MM(5/64)

(7 x 7 )

2.4MM(3/32)

(7 x 7 )

3.2MM(1/8)

(7 x 19 )
20 x 35mm JP-1235
25 x 42mm JP-1225 JP-1625
30 x 52mm JP-1230 JP-1630 JP-2030
35 x 60mm JP-1235 JP-1635 JP-2035
38 x 66mm JP-1238 JP-1638 JP-2038 JP-2438
40 x 69mm JP-1240 JP-1640 JP-2040 JP-2440 JP-3040
50 x 86mm JP-1250 JP-1650 JP-2050 JP-2450 JP-3050
60 x 104mm JP-1260 JP-1660 JP-2060 JP-2460 JP-3060
70 x 120mm JP-1270 JP-1670 JP-2070 JP-2470 JP-3070
76 x 131mm JP-1276 JP-1676 JP-2076 JP-2476 JP-3076
80 x 138mm JP-1280 JP-1680 JP-2080 JP-2480 JP-3080
90 x 154mm JP-1290 JP-1690 JP-2090 JP-2490 JP-3090
100 x 173mm JP-12100 JP-16100 JP-20100 JP-24100 JP-30100
120 x 206mm JP-12120 JP-16120 JP-20120 JP-24120 JP-30120

Stainless steel ferrule mesh, the stainless steel grade includes type304, type304L, type316, type316L.

The structures of the stainless steel wire cable mesh have two kinds: 7 x 7 and 7 x 19. The standard stainless steel wire cable diameter includes 1/8", 3/32", 1/12", 1/16", and 3/64", the standard mesh opening size includes 2" x 2", 3" x 3" and 4" x 4".
The flexible stainless steel wire cable mesh's rhombus mesh has excellent flexible performance, virtually indestructible, most impacting-resistant and breaking resistant force, most resisting rain, snow and hurricane.

Because of the material is virtually indestructible stainless steel, it can be safely contain any species on land, in the air indoors or out. And the weave opening, we can infinitely customizable to meet your exhibits exact specifications. No matter how large, how small, or how cunning you specimens are, we assure their complete security.

2. Application of Cable Mesh Railing :

Balustrade Infill Cable Mesh Railing Black Oxide , AISI Stair Barrier Safety Nets

Balustrade Infill System With Bridge Stairway AIS316 Flexible Stainless Steel Cable Netting
