Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel
Specifications
Brand Name :
Jianping
Model Number :
JP
Certification :
CE , SGS
Place of Origin :
Hebei, China
MOQ :
5 pcs
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
12000 pcs / month
Delivery Time :
5-8 Work Days
Packaging Details :
Carton
Product Name :
Heavy Duty Overhead Line Pulling Grip for Cable
Material :
GALVANIZED STEEL, stainless steel/ hot galvanized steel
Certificate :
ISO9001/ SGS
Mesh length :
140-2100mm
Size :
6-320mm
Usage :
Pull-through Cable
Application :
cable protection, cable changing..etc
Package :
plastic bag and carton box
High Light: :
Cable Grip Cable Sock/Cable Pulling Grips
Description

Heavy Duty Cable Pulling Grips/Hoisting Grip/Wire Mesh Grip/Cable Pulling Grips

Heavy Duty Cable Pulling Grips/Hoisting Grip/Wire Mesh Grip/Cable Pulling Grips
Description

Heavy Duty Pullling Grip

Details

* Suitable for PVC and rubber insulated cables

* Sizes from 25-37mm diameter (1-1.45 Inches)

* Measured by the outside diameter of the cable

* Simply insert cable end into the sock then stretch out

* The harder you pull, the harder they grip

* These should be pulled using rope, not a cable snake or fiberglass rodder

* Made of 304 stainless steel

* Pulling Grips have either single or double eye for attaching to the pulling rope.

* The correct pulling grips eases low and high voltage cable pulling into ducts, trenches and conduits.
* Provide an efficient method for cable installation and support within their load carrying capacity.

* Pulling grips feature a double weave of galvanized steel for greater strength and added mesh contact with the cable as well as a forged steel compact flexible eye, which can be attached to a swivel.

* Double weave variable mesh design provides added strength and greater mesh contact on the cable.
* They are designed to handle longer or heavier pulling jobs such as an installation of underground Cables, communication lines and service lines.
* Used in factories, construction sites and utility work.

Heavy Duty Cable Pulling Grips/Hoisting Grip/Wire Mesh Grip/Cable Pulling Grips
Product type
Strong type draging cable grip
Size
1/4, 3/8, 1/2, 5/8, 7/8, 1-1/4, 1-3/8, 1-5/8, 2-1/4, 3, 4, 5 in or any other sizes
Material
Stainless steel, Galvanized steel
Delivery
Within 7-15 days
Sample
Avaliable

Heavy Duty Cable Pulling Grips/Hoisting Grip/Wire Mesh Grip/Cable Pulling Grips
Part Number
Cable Diameter
Eye Diameter
Mesh Length
Approx Break Strength
JPCS010
0.25-0.49"
(6.4-12.5mm)
7/8"(22.2mm)
26"(660.4mm)
6800 lbs.
JPCS016
0.50-0.74"
(12.7-18.8mm)
1"(25.4mm)
32"(812.8mm)
10000 lbs.
JPCS022
0.75-0.99"
(19.1-25.1mm)
1"(25.4mm)
41"(1041.4mm)
14400 lbs.
JPCS025
1.00-1.24"
(25.4-31.8mm)
1-3/8"(34.9mm)
52"(1320.8mm)
24600 lbs.
JPCS032
1.25-1.49"
(31.8-37.8mm)
1-5/8"(41.3mm)
56"(1422.4mm)
30600 lbs.
JPCS038
1.50-1.74"
(38.1-44.2mm)
1-7/8"(47.6mm)
60"(1524.0mm)
30600 lbs.
JPCS050
2.00-2.49"
(50.8-63.3mm)
1-7/8"(47.6mm)
50"(1270.0mm)
48000 lbs.
JPCS060
2.50-2.99"
(63.5-76.0mm)
1-7/8"(47.6mm)
52"(1320.8mm)
48000 lbs.
JPCS070
3.00-3.49"
(76.2-88.6mm)
1-7/8"(47.6mm)
54"(1371.6mm)
48000 lbs.
JPCS080
3.50-3.99"
(88.9-101.3mm)
1-7/8"(47.6mm)
56"(1422.4mm)
48000 lbs.

Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel

Heavy Duty Cable Pulling Grips/Hoisting Grip/Wire Mesh Grip/Cable Pulling Grips

Types of Grip Cable Pulling Grips

Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel

fiber optic pulling grips light duty pulling grips junior pulling grips

Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel

heavy duty pulling grips multi-weave pulling grips whipsocks

Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel

slack pulling grips stable pulling grips nylon pulling grips

Heavy Duty Cable Pulling Grips/Hoisting Grip/Wire Mesh Grip/Cable Pulling Grips Applications

1. Telecom cable
2. Fiber cable
3. Coaxial cable
4. Feeder cable
5. Hybrid cable
6. Corrugated cable
7. Smooth cable
8. Braid cable

Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel

Heavy Duty Wire Mesh Cable Pulling Grips Cord Grips 304 Hoisting Grip Stainless Steel

3.FAQ

1.How long is the warranty ?

Our products have 12 months warranty , and the product have high quality.

2.How to get a sample?

We can send you samples for free ,but you need pay the express charge.

3.Which payment terms is available?

We accept paypal,western union,visa,escrow, payment by T/T in advance or LC.

4.Can you produce according to the samples?

Yes, we can produce by your samples or technical drawings.
