Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Specifications
Brand Name :
FANBAO
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
150sets per month
Delivery Time :
5-8 work days
Packaging Details :
standard export wooden case
mixing tank size :
100L to 20000L
mixer power :
1.5kw-11kw. or customizable
Homogenizer Speed :
2940RPM
Material :
Stainless Steel
Surface Finish :
Mirror Polish
Supporting Legs :
Adjustable
Motor Power :
0.55-55KW
Control System :
PLC
Heating Method :
Electric Heating
Application :
Food, Beverage, Pharmaceutical, Chemical, etc.
Tank Shape :
Cylindrical
Mixing Mode :
Continuous
Description
Stainless Steel Tank Agitator Mixer Pneumatic Stirrer High Shear Emulsifier
Key Specifications
Mixing Tank Size
100L to 20000L
Mixer Power
1.5kw-11kw or customizable
Homogenizer Speed
2940RPM
Material
Stainless Steel
Surface Finish
Mirror Polish
Motor Power
0.55-55KW
Control System
PLC
Applications
Food, Beverage, Pharmaceutical, Chemical industries
Product Overview
Our stainless steel high shear emulsifier is a custom-configured homogenizing system designed for emulsification and stirring processes under vacuum conditions. This versatile equipment can be equipped with low-speed wall scraping for high viscosity products or high shear emulsification for dispersion, homogenization, and mixing applications.
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Customizable Configuration Options
Profile/Type Singlelayer Tank Double Layers Tank Three Layers Tank
Material SS304L, SS316L
Volume 100L-20000L
Tank Type Vertical, Horizontal, Mobile
Heating Method Electric Heating, Steam Heating
Stirrer Type Impeller, Anchor, Turbine, High Shear, Magnetic Mixer
Standard Features
  • Quick open manhole / Pressure manhole
  • Various types of CIP cleaners
  • Sterile respirator
  • Adjustable legs for stability
  • Sanitary inlet and outlet valves
  • Customizable thermometer and liquid level meter
  • Optional paddle blender and ladder
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
Technical Specifications by Model
Model Heater (KW) Mixer (KW) Mixer Speed (RPM) Homogenizer (KW) Homogenizer Speed (RPM)
DFM-200L 6 1.5 0-63 4 2890
DFM-300L 9 2.2 0-63 4 2890
DFM-500L 18 3-4 0-63 5.5 2900
DFM-1000L 27KW/steam 4-5.5 0-63 7.5 2900
DFM-2000L 27KW/steam 5.5 0-63 11 2930
DFM-3000L 36KW/steam 7.5 0-63 15 2930
DFM-5000L 48KW/steam 11 0-63 22 2940
Customizable All specifications can be customized to customer requirements
Operation Principle
The high shear dispersing emulsifier efficiently distributes one phase into another consecutive phase through rapid rotor movement. This creates strong mechanical and liquid shearing forces in the narrow space between stator and rotor, resulting in instantaneous dispersion and emulsification. The system combines centrifugal force, liquid fraction, and mechanical impact to produce stable, high-quality products with particle sizes as fine as 2-2 microns.
Stainless Steel Tank Ibc Tote Agitator Pneumatic Stirrer High Shear Emulsifier
