Specifications
Brand Name :
Winsmart
Model Number :
SMTDR6
Certification :
CE
Place of Origin :
China
MOQ :
1 Unit
Price :
USD15000-30000/unit
Payment Terms :
T/T
Supply Ability :
300 units per year
Delivery Time :
14-20 working days
Packaging Details :
plywood case
Safetyfeatures :
Emergency Stop Button, Overload Protection
Application :
Surface Mount Technology (SMT) Glue Dispensing
Operatingspeed :
Up to 1000 points per minute
Workingtemperaturerange :
0°C to 45°C
Powersupply :
AC 220V, 50/60Hz
Type :
Automatic Glue Dispensing Machine
Materialcompatibility :
Epoxy, Silicone, UV Glue, Conductive Adhesives
Dispensingaccuracy :
±0.01 mm
Repeatability :
±0.005 mm
Productname :
SMT Glue Dispensing Machine
Controlsystem :
PC control
Weight :
150 kg
Maxdispensingspeed :
100 mm/s
Glueviscosityrange :
10-5000 cps
Operatingtemperature :
0-45°C
Nozzlediameter :
0.1 mm - 2.0 mm
Machinetype :
Semi-auto
Description
Dual Table Desktop Precise SMT Glue Dispenser Machine
Desktop SMT Glue Dispenser Machine Introduction:

A Desktop Precise SMT Glue Dispenser Machine is a compact, benchtop system designed to apply adhesive materials such as epoxy, UV glue, or solder paste with high precision onto printed circuit boards (PCBs) or other small electronic assemblies. Unlike inline systems used in high-volume production lines, desktop machines are ideally suited for prototyping, small-batch production, R&D, and repair work.
These machines use XYZ gantry systems, precision stepper motors, and micro-dispensing valves or syringes to control the amount and placement of glue for SMT components.

Desktop SMT Glue Dispenser Machine Applicable Glue:

Thermal conductive adhesive, SMT bottom filling, component packaging, solder paste, red glue, black glue, semiconductor packaging, crystal cell fixation, etc

Desktop SMT Glue Dispenser Machine Features:
  • PC control, Windows operating system, fault sound and light alarm, and menu display.
  • CCD visual positioning system.
  • Adopting servo motor and screw drive.
  • Capable of carrying: pneumatic injection valve, piezoelectric valve, screw valve, AB rubber valve, etc.
  • Optional laser height detection system, which can automatically calibrate the Z-axis height after workpiece deformation.
  • Optional workpiece heating system to enhance the fluidity of the coating during bottom filling.
  • Optional precision weighing system, intelligent control and detection of dispensing amount, ensuring consistency of dispensing.
Desktop SMT Glue Dispenser Machine Specifications:
Model SMTDR6
Working Stroke 200x300mm, dual tables
Moving Speed Max 800mm/s
Driven Mode servo + screw rod
Program Mode Visual CCD System
Repeatable Precision ±0.02mm
Max Load(Y/Z axis) 10/5kgs
Working Humidity 20-90%
Number of axis 4
PC System Windows 10
Dimension (W*D*H) 950x850x850mm
Weight 150kgs

Desktop SMT Glue Dispenser Machine Applications:
Application Details
PCB Prototyping Apply adhesive to secure components before reflow or wave soldering.
Wearables & IoT Devices Perfect for small PCBs used in compact consumer electronics.
Component Repair & Rework Used to reapply adhesive in repair scenarios.
Automotive Electronics For custom automotive electronics or sensor assembly.
Medical Device Assembly Precise glue application for miniaturized, high-reliability medical PCBs.
R&D Labs Used in electronics research labs to test new component arrangements.
Low-Volume SMT Assembly Ideal for startups producing small batches of electronics.
Conformal Coating Pre-Application

Spot-gluing components before coating processes.
