Industrial Electronics Momentary Push Button Switch Multi - Position Models
Industrial Electronics Momentary Push Button Switch Multi - Position Models
Industrial Electronics Momentary Push Button Switch Multi - Position Models
Industrial Electronics Momentary Push Button Switch Multi - Position Models
Specifications
Brand Name :
BZCN
Model Number :
TS-D001
Certification :
SGS
Place of Origin :
China
MOQ :
1000 pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000000 pcs per week
Delivery Time :
3 days
Packaging Details :
1000 pcs per bag
Push :
Horizontal
Type :
Snap in
Rating :
50mA
Voltage :
12V
Button :
Black
Operation :
Momentary
Description

White house with black button 6*6 mm thru hole momentary push button tactile switch​

Multi-pole and multi-position models with variety of indexing options for low current to 12 amp applications. 1/2 inch version. Shorting and non-shorting contacts.

  • Industrial electronics
  • Medical equipment
  • Automotive
  • Snap acting momentary

Features.

Suitable for high density mounting.

Reflow solderable.

THT Through hole terminal.

Spec.

Model No. TS-D001
Terminal Type DIP
Switch Rating 50mA DC 12V
Operation Travel 0.2±0.1mm
Operation Tpye Single throw single pole
Operation Force 160/180/250 gf
Operation Life 300,000 Cycles
Contact Resistance ≤100mΩ max
Insulation Resistance ≥100MΩ/m DC 250V
Dielectric Strength AC 250V/m 50Hz
Operation Temperature -30℃ to + 85℃
Operation Humidity 25-85% RH
Solder Ability 260±5℃ for 3 seconds

Reference.
