4 Pin Momentary Push Button Switch Thru Hole Terminal With Blue House
4 Pin Momentary Push Button Switch Thru Hole Terminal With Blue House
4 Pin Momentary Push Button Switch Thru Hole Terminal With Blue House
4 Pin Momentary Push Button Switch Thru Hole Terminal With Blue House
Specifications
Brand Name :
BZCN
Model Number :
TS-F001
Certification :
SGS
Place of Origin :
China
MOQ :
1000 pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000000 pcs per week
Delivery Time :
3 days
Packaging Details :
1000 pcs per bag
Push :
Horizontal
Material :
PA66
Rating :
50mA
Voltage :
12V
Dust proof :
Acceptable
Operation :
Momentary
Description

blue house with black button Thru hole terminal 4 pin momentary push button tactile switch

Miniature and ultra-miniature tact and dome switches for printed circuit board mounting.

Features.

Applications:

  • automotive (air bags, heating/AC, door handles, column switches)
  • aerospace (main cabin lights, flight attendant buttons)
  • consumer (cell phones, headsets, remote controls, wearable electronics)
  • medical (hearing aids, health diagnostics, portable equipment)

Spec.

Model No. TS-F001
Terminal Type DIP
Switch Rating 50mA DC 12V
Operation Travel 0.2±0.1mm
Operation Tpye Momentary
Operation Force 160/180/250 gf
Operation Life 300,000 Cycles
Contact Resistance ≤100mΩ max
Insulation Resistance ≥100MΩ/m DC 250V
Dielectric Strength AC 250V/m 50Hz
Operation Temperature -30℃ to + 85℃
Operation Humidity 25-85% RH
Solder Ability 260±5℃ for 3 seconds

Reference.
