56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
Specifications
Brand Name :
Sirivision
Model Number :
SR-SG2428FC
Certification :
CE, ROHS, FCC, UKCA
Place of Origin :
Shenzhen，China
MOQ :
20
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000pcs Per Month
Delivery Time :
5-8 work days
Packaging Details :
1pc in box, 1pc Warranty Card in box
Product Name :
24G Ports, 4SFP And 4 Combo Ports Easy Smart Gigabit PoE Switch
SFP Fiber Port :
4 Ports
MAC Address Table :
8K
RJ45 Port :
24
Manage :
Layer 2
Switching Capacity :
56Gbps
Description

24 Ports And 4 SFP Fiber Ports Easy Smart Gigabit Ethernet Managed Switch SR-SG2428FC

Easy Smart Full Gigabit Switch With 24 10/100/1000M RJ45 Ports And 4 SFP Fiber Ports

Description Of The Managed Poe+ Switch:

SR-SG2428FC is a full Gigabit switch with 24 10/100/1000Mbps RJ45 adaptive ports, 4 Combo ports and 4 SFP fiber ports . It supports various functions, such as IGMP Snooping, static link aggregation, Port Mirroring, 802.1Q VLAN, etc. It is suitable for campus, hotel and enterprise campus network access and aggregation scenarios.

Features Of The Sfp Managed Switch:

  • Provide 24 10/100/1000Mbps Auto-sensing RJ45 ports, 4 10/100/1000Mbps SFP fiber ports.
  • Full-duplex flow control conforms to IEEE 802.3x standard, and half-duplex adopts Backpressure standard.
  • Support Port-Based/802.1p/DSCP priority QoS.
  • Tag VLAN based on IEEE 802.1Q.
  • Support 802.1q VLAN, Storm Control, and Port Mirroring.
  • Support MAC address automatic learning, automatic aging and aging time setting.

Product Spectification Of The Sfp Switch 4 Port:

SR-SG2428FC
Power Supply AC100~240V 50/60Hz
Standards IEEE 802.3i,802.3u,802.3ab,802.3x,802.3z
Ports

24 10,100,1000Mbps RJ45 ports, 4 Gigabit SFP fiber ports
Indicators Electrical port indicators, SFP fiber port indicators, power input indicator, system running indicator.
Network
medium		 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF
Dimensions 440*190*44.5 mm
Transfer Method Store-and-Forward
MAC Address Table 8K
Switching Capacity 56Gbps
Packet Forwarding Rate 41.664Mpps
Packet Buffer 4.1Mbit
Jumbo Frame 10KBytes
Environment Operating Temperature: 0℃ ~45℃ (0℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing

Soft Features:

L2 Switching Features • IGMP Snooping
- Supports IGMP Snooping
• Link Aggregation
- Supports static link aggregation
• Port Mirroring
• Cable Test
VLAN • Supports up to 32 VLANs (out of 4K VLAN IDs
• MTU/Port/802.1Q VLAN
Quality of Service
(QoS)		 • Support Port-based/802.1p/DSCP priority
• Support 4 priority queues
• Storm Control
• Rate Limit
Management

• Web-based Graphic User Interface (GUI)

• Smart-Configuration Utility
Ethernet Protocols • IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX/FX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3x Flow Control
• IEEE 802.1q VLANs/VLAN tagging
• IEEE 802.1p QoS

Product Application Of The Manageable Poe Switch:

56Gbps Gigabit Easy Smart Switch 24 Ports 4 Combo Ports 4SFP
