12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
Specifications
Brand Name :
Sirivision
Model Number :
SR-SG8808MN
Certification :
CE, ROHS, FCC, UKCA
Place of Origin :
Shenzhen，China
MOQ :
20
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000pcs Per Month
Delivery Time :
5-8 work days
Packaging Details :
1pc in box, 1pc Warranty Card in box
Manage :
Layer 2
MAC Address Table :
4K
Jumbo Frame :
10K
Cache :
1.5Mbit
Ethernet Port :
8 Ports
Power Supply :
12V DC/1A
Description

12V 8 Ports Gigabit Switch, 8 10,100,1000M Auto-Negotiation Ethernet Ports, QoS SR-SG8808MN

Easy Smart Full Gigabit Switch With 8 10/100/1000M Ports

Description Of The 8 Port Managed Gigabit Switch:

SR-SG8808MN is a Gigabit Web smart switch equipped with 8 10/100/1000Mbps RJ45 adaptive ports. It can provide users with network monitoring to observe traffic behavior.

Features Of The Fanless Managed Switch:

  • Support IEEE 802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3az.
  • Provide 8 10/100/1000Mbps auto-sensing RJ45 ports.
  • Easily configure it by the web-based user interface or management utility.
  • With Port Mirroring, DHCP snooping features, it can identify and even locate connection problems on your business network.
  • Administrators can designate the priority of the traffic based on Port Priority, 802.1P and DSCP Priority, to ensure that voice and video are always clear, smooth and lag-free.
  • Dynamic LED lights provide real-time work status display and basic fault diagnosis.

Product Spectification Of The Best 8 Port Managed Switch:

SR-SG8808MN
Power Supply 12V DC/1A
Standards IEEE 802.3i,802.3u,802.3ab,802.3x,802.3z
Ports 8 10,100,1000Mbps RJ45 ports
Indicators

8 electrical port speed indicators, 8 electrical port link/act indicators,

power input indicator
Network
medium		 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF
Dimensions 160 * 95 * 30 mm
Transfer Method Store-and-Forward
MAC Address Table 4K
Switching Capacity 16Gbps
Packet Forwarding Rate 11.904Mpps
Packet Buffer 1.5Mbit
Jumbo Frame 9KBytes
Environment Operating Temperature: 0℃ ~45℃ (0℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing

Soft Features:

L2 Switching Features • IGMP Snooping
- Supports IGMP Snooping
• Link Aggregation
- Supports static link aggregation
• Port Mirroring
• Cable Test
VLAN • Supports up to 32 VLANs (out of 4K VLAN IDs
• MTU/Port/802.1Q VLAN
Quality of Service
(QoS)		 • Support Port-based/802.1p/DSCP priority
• Support 4 priority queues
• Storm Control
• Rate Limit
Management

• Web-based Graphic User Interface (GUI)

• Smart-Configuration Utility
Ethernet Protocols • IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX/FX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3x Flow Control
• IEEE 802.1q VLANs/VLAN tagging
• IEEE 802.1p QoS

Product Application Of The 8 Port Managed Switch:

12V 8 Ports Full Gigabit Switch 10 100 1000M Auto Negotiation QoS SR-SG8808MN
