Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Specifications
Brand Name :
SINOLINK
Model Number :
GS150
Certification :
CE
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
USD+850-950+set
Payment Terms :
T/T
Supply Ability :
300+set+per+month
Delivery Time :
30 days after payment
Packaging Details :
Plywood box 920X760X1100mm
Power :
15hp gasoline engine power
Blades :
2pcs fly blades and 1pcs fixed blade
Wheel :
5.7-8
chipper weight :
270kg
Max chipper diameter :
120mm
Description
Wood Chipper 15hp Gasoline Powered ATV Forestry Farm Log Tree Branch Chipper Shredder Wood Processor Chipping Machine
Extra Wide Chipper Opening
This impressive garden shredder also has a convenient extra-wide chute opening,
allowing you to feed in more established branches without doing too much chopping
beforehand to break them up.
Easily Portable
Thanks to its portable design, with large 16” wheels and attached trailer ball, you can easily tow the
shredder to wherever it is needed (for off-road use only). It even comes with an in-built levelling jack
so you can safely use this wood chipper on uneven or sloping ground.
GS150 wood chipper Specifications
Model GS150
Start Method Electric or Recoil
Drive Type Belt Drive
Chipping Capacity (mm) 120
Feed Hopper Opening Size (mm) 500x460
Infeed Throat Opening Size (mm) 160x176
Disc Size (mm) (Diameter / Thickness) 550 x 20
Knives 2
Features ATV Towing Bar, 360° Rotating Chute
Handle Type N/A
Safety Features Stop Button
Engine Model Loncin 420FD or B&S XR2100
Engine Type 4 Stroke OHV Single Cylinder
Engine Size (cc) 420
Rated Power (hp) 15
Disc Speed (RPM) 2200
Fuel Petrol
Fuel Capacity (L) 6.5
Engine Oil SAE30
Engine Oil Capacity (ml) 1100
Gross Weight (kg) 270
Tyres 5.7-8
Off Road Tow Bar Yes
Fully Assembled Dimensions (H x W x L) (mm) 2550 x 1010 x 1810
Package Dimensions (H x W x L) (mm) 1250 x 770 x 1050
Fuel Type / Power Source Petrol
Product Type Wood Chipper
Warranty (years) 1
Commercial Warranty (years) 1
In The Box Petrol Wood Chipper, Tool Set, Manual

Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
There is an Emergency stop Bar at the feeder hopper.

When it is depressed it cuts off the engine.
As the engine reduces speed the clutch will release and the Disc will begin to slow down.
Easy access inside the disc cover to the disc and blades via a quick release latch.

The disc cover has a micro switch to stop the engine being started with the cover open.
The exit shoot, can swivel 360°, throwing the chip into a nearby trailer or pile.

Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher

LONCIN 420cc 27Nm
Easy Pull Start
Double Belt with Clutch (no load during starting)
Capacity 4” 100mm - cutting point is 160Wx 200H (mm)
360° Rotating Discharge Chute
Double Blades (reversible)
Anvil: Adjustable
Large feed shoot, with gravity self feed.
LED tail light and NZ & pin plug
Tyres: E-Mark 5.7-8 Road Tyre
Folding height adjustable jockey wheel
Coupling 1 7/8”
Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
Extremely strong and robust. Main housing is made of 5mm steel plate, and the base of 4mm plate.

10mm bearing boss plate.
Weight: 260kgs

Sinolink Wood Chipper Machine Yard 15hp Petrol Garden Mulcher
