1.1 A 43-inch high-brightness LCD screen is selected.

1.2 The luminance requirement is 2000 cd/m² , featuring automatic ambient light sensing and tempered explosion-proof glass.

1.4 The system features high-performance cooling fans with integrated protection against lightning, overload, overvoltage, overcurrent, and overheating. Its robust design ensures rainproof, dustproof, and sunburst-resistant performance.

1.5 Functional requirements: The device must feature an Android-based motherboard, support Wi-Fi and RJ45 ports, allow simultaneous control of all devices or individual control of a single unit, and support full HD 1920x1080 video decoding.

• Elegant Design: Featuring a standard shell, we offer custom-designed, sophisticated and stylish shells tailored to your needs, available in diverse styles with premium quality.
• Timed backlight: Supports 10 preset time slots for adjustable backlighting, user-friendly operation.
• Smart temperature control: The system maintains a constant, dry internal environment to prevent fogging and condensation.
• Dust and water resistance: The fully enclosed design prevents external dust and water from entering, meeting IP55 protection rating.
• Sun protection and explosion-proof: The housing is made of galvanized steel plate, treated with specialized outdoor powder coating, waterproofing, sun protection, corrosion resistance, and explosion-proof surface technology; it can withstand outdoor use for up to 10 years without fading.

• (1) Featuring industrial-grade high-reliability modular design, it offers user-friendly operation, aesthetic appeal, easy maintenance, and comprehensive protective measures.
• (2) High resolution, high contrast, and high brightness significantly enhance the depth of the image, allowing for better detail representation.
• (3) Features automatic ghost elimination, UV protection, solar heat insulation, and energy-saving LCD screen with green light-sensing technology for prolonged use.
• (4) It has the function of black level extension and adaptability, which can enhance the depth of the image.
• (5) Featuring industrial-grade LCD screens, the video displays offer brighter colors and enhanced 3D immersion.
• (6) 16.7 million colors deliver a more natural and refined image, with truly seamless motion.
• (7) Features intelligent temperature control, eco-friendly design, and quiet operation with high reliability and excellent stability, making it ideal for harsh working environments.
• (8) Ultra-long lifespan, with 7*24-hour continuous operation capable of exceeding 60,000 hours.
• (9) Equipped with a wide-temperature LCD panel, capable of operating in environments ranging from-40°C to +85°C.

• (1) The cabinet features a fully galvanized steel shell with an imported metallic paint finish on the exterior. It incorporates anti-magnetic, anti-static, and waterproof materials, achieving IP55-rated waterproofing for all-weather outdoor use. The design also includes anti-theft and explosion-proof features.
• (2) High-reliability electrical protection: leakage current, overload, overvoltage protection, lightning protection devices, and overtemperature protection.
• (3) Audio: Features a dual-channel stereo surround amplifier system with 8Ω output and 2*10W power.
• (4) The working environment temperature is designed to operate within a range of +85°C to-40°C, with cooling achieved through high-performance combined fans.
• (5) Protective glass: 6mm tempered explosion-proof glass.
• (6) All systems of the machine adopt modular design principles, with sustainable and maintainable design.
• (7) Machine fixation method: Multiple M18-24 screw columns are cast from the ground and threaded into the machine base, then secured with nuts.
• (8) Light Sensing System: The screen backlight employs automatic ambient light sensing, dynamically adjusting brightness to ensure clear image display under direct sunlight while preventing glare and energy waste at night.

3.3 Playback Content

• (1) Utilize digital outdoor electronic displays to showcase a diverse range of content, including images, animations, and videos, thereby highlighting the cutting-edge nature of community outreach.
• (2) Play lively and vivid video content to enhance the appeal of promotional materials. Incorporate interactive touch features to engage the audience, attract public attention, and foster effective communication.
• (3) With the smart network system, content can be streamed across multiple devices nationwide without leaving home.

parameter :
