distance measurement device CUI CUSA-T80-15-2400-TH ultrasonic sensor with 15 meter detectable range
distance measurement device CUI CUSA-T80-15-2400-TH ultrasonic sensor with 15 meter detectable range
distance measurement device CUI CUSA-T80-15-2400-TH ultrasonic sensor with 15 meter detectable range
distance measurement device CUI CUSA-T80-15-2400-TH ultrasonic sensor with 15 meter detectable range
Specifications
Functional Type :
Transmitter
Operating Temperature :
-20℃~+80℃
Description :
Transmitter Through Hole,D=9.8mm Ultrasonic Receivers, Transmitters RoHS
Mfr. Part # :
CUSA-T80-15-2400-TH
Model Number :
CUSA-T80-15-2400-TH
Package :
Through Hole,D=9.8mm
Description

Product Overview

The CUI DEVICES CUSA-T80-15-2400-TH is an ultrasonic sensor featuring an aluminum can and an open-type transmitter. It offers a detectable range of up to 15 meters and operates at a frequency of 40 kHz with a sensitivity of -75 dBV. This sensor is designed for applications requiring precise distance measurement and detection.

Product Attributes

  • Brand: CUI DEVICES
  • Material: Aluminum (can), Iron with tin plating (terminal pins)
  • Certifications: RoHS

Technical Specifications

ModelTypeFrequencyOperating VoltageSound Pressure LevelDirectivityCapacitanceDetectable RangeDimensionsOperating TemperatureWeight
CUSA-T80-15-2400-THTransmitter40 kHz80 Vp-p105 dB (at 10 V, 30 cm, sine wave)80 degrees1,800 - 3,000 pF (at 1 kHz)0.2 - 15 m9.8 x 7.0 mm-20 to 80 C0.74 g

2410122020_CUI-CUSA-T80-15-2400-TH_C4360734.pdf
